Using CAT.5 network patch cords support power for the wireless AP/CPE and IP/PTZ camera.
FE ports can support 250 meters long distance transmission automatically
6KV lightning protection,8KV surge protection, anti-reverse connection, over-current protection, over-voltage protection, over-temperature protection, Short circuit protection
Support 60W PoE receiving power, free of power adapter & simplify power supply
The Max output power of the port is 60W, which is convenient for hi-power equipment
Zero configuration feature power supply is automatically supplied to the adaptive equipment
- Networking standard
- IEEE802.3af/at/bt.
- PoE Watchdog AI Function
- Detection front-end PoE cameras and PD, Automatic detection, Automatic restart
- Network Port
- PoE (1~3) :10/100Mbps PoE ports (RJ45) PoE (4) :10/100Mbps PoE port, BT port, Compatible uplink port (RJ45) LAN (1~2):10/100Mbps uplink port (RJ45)
- Switch Capacity
- Bandwidth 1.2 Gbps
- PoE Standard
- IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3x Flow Control IEEE 802.3af/at/bt Power over Ethernet
- Transmission Distance
- 100Mbps /10Mbps Adaptive MAX 250m
- MAC Address List
- 2K
- Lightning Protection
- 6KV, Per: IEC61000-4-5
- PoE Power Budget
- 65W
- Power Source
- AC 180~240V Total ≤65W
- Working Temp
- -30°C ~60°C
- Humidity
- 10%~90% (Non-condensing)
- Storage Temperature
- -40°C ~70°C
- Storage Humidity
- 5%~90% (Non-condensing)
- Dimension
- 187mm(L) x 139mm(W) x 43mm(H)
