English
Using CAT.5 network patch cords support power for the wireless AP and IP camera.
Upload port automatic flip (Auto MDI / MDIX).
6KV lightning protection, 8KV surge protection, anti-reverse connection, over-current protection, over-voltage protection, over-temperature protection, Short circuit protection.
The port power is 60 watts, it is convenient for high-power device.
Zero configuration feature power supply is automatically supplied to the adaptive equipment.
- Networking standard
- IEEE802.3af/at/bt.
- PoE Watchdog AI Function
- Detection front-end PoE cameras and PD, Automatic detection, Automatic restart.
- Network Port
- PoE (1~6): 10/100Mbps PoE ports (RJ45) PoE (7~8): 10/100Mbps PoE ports, BT port, Compatible uplink ports (RJ45) LAN: 10/100/1000Mbps uplink ports (RJ45)
- Network Standard
- IEEE 802.3i 10 BASE-T IEEE 802.3u 100 BASE-TX/ IEEE 802.3ab 1000 BASE-TX IEEE 802.3x Flow Control IEEE 802.3af/at/bt Power over Ethernet
- Transmission Rate
- 2000Mbps Full Duplex; 10 or 1000Mbps Half Duplex
- Transmission Distance
- 1~130m
- MAC Address Table
- 8K
- Bandwidth
- 5.6 Gbps
- Network Latency
- (10 to 1000Mbps): ≤16μs (use the 64byte package size)
- Frame Filter & Transmission Rate
- 14800pps the most for 10Mbps port, 148800pps the most for 100Mbps port, 1488000pps the most for 1000Mbps port
- Power Budget
- 120W
- Packet Buffer
- 4Mbit
- Power Input
- AC 180~240V, Total: ≤120W
- PoE Watchdog
- Port 1~8
- Power Output
- PoE 1~6 Port: 1/2(+52V), 3/6 (GND)≤30W PoE 7~8 Port: 1245(+53V), 3678 (GND) compatible 1/2 (+52V), 3/6 (GND)≤60W
- Lightning Protection
- 6KV, Per: IEC61000-4-5
- ESD Protection
- 8KV, Per: IEC61000-4-2
- Operating Temperature
- -30°C ~60°C
- Operating Humidity
- 10%~90% (Non-condensing)
- Storage Temperature
- -40°C ~70°C
- Storage Humidity
- 5%~90% (Non-condensing)
- Dimension
- 187mm(L) x 139mm(W) x 43mm(H)
- Weight
- 1Kg
- Warranty
- 2 Year
- Package Content
- AC Power Cable, Installation Manual
