Universal AC Input/ Full Range
LED Indicator For Power on For Output
Long Distance Voltage Drop Adjustment with Cable Compensation Switch
Low Ripple Voltage, Low Energy Consumption with High Efficiency
Stabilize Output with Low Interference
- Input AC Voltage Range
- 170V~250V AC
- Input AC Voltage Rated
- 220-240V AC
- AC Current (Typ.)
- 2A@90VAC
- Rated Power
- 72W
- Inrush Current (Typ.)
- COLD START 40A@230V AC
- Leakage Current
- < 2mA@230VAC
- Efficiency (Typ.)
- ≥ 85%
- Frequency Range
- 50Hz
- Output DC No Load Rated Voltage
- 12-12.5V, 14V-14.5V, 15-15.5V
- Output DC On Load Rated Voltage
- 11.2-12.6V, 13.2-14.2V, 14.2-15.2V
- Output DC Current Range
- 0-5A, 0-4.25A, 0-4A
- DC Power (Pout) Max
- 60W, 60W, 60W
- Ripple & Noise (max.)
- <240mV, <270mV, <300mV
- Load Efficiency
- 85%, 86%, 86%
- Setup Start up Time
- < 2S@230VAC
- Line Regulation
- ±2%
- Load Regulation
- ±2%
- Lead Cable Compensation
- <3% OF DC NO LOAD VOLTAGE
- Over Voltage Protection
- Support
- Over Current Protection
- YES, 110%-150%OF RATED CURRENT
- DC Short Circuit
- YES With Auto Restart Function
- Over Temperature
- Hiccup Mode, recovers automatically after faults removed
- Safety Standard
- IEC-60950-1-2005/IS-13252(PART-1):2010
- Withstand Voltage
- I/P-O/P:3KVAC, I/P-FG:1.5KVAC, O/P-FG:1.5KVAC
- Isolation Resistance
- I/P-O/P, I/P-FG,O/P-FG:100Mohm/500VDC
- Production Isolation
- CLASS-II
- IP Protection
- IP20
- EMC Immunity
- SURGE SUSCEPTIBILITY IEC-61000-4-5 L TO N AND N TO L, LEVEL-3 , 3KV/ 2 ohm, (0°/90°/270°) ±5 TIMES ESD, IEC-61000-4-2 LEVEL3 8KV AIR, LEVEL 2 4KV CONTACT
- Working temperature
- 0 to +40°C
- Working Humidity
- 10% ~ 95%RH
- Case Temperature
- ≤70°C
- Dimension
- 165mm x 115mm x 35mm
- Body Type
- PC-FR-4
- Weight
- 245gm
