8, 1000Mbps; RJ45 ports; Max. 30W Output of Single PoE Port
Support IEEE802.3i/802.3u/802.3x/802.3af/802.3ab
- 2, 1000Mbps; Transmission Distance
- 0-100m
- Uplink Ports
- 2, 1000Mbps; Transmission Distance: 0-100m
- Network Protocol
- IEEE802.3i/802.3u/802.3x/802.3af/802.3ab
- Switch Capacity
- 20Gbps Full duplex
- Packet Forwarding Rate
- 1.488Mpps/port
- Port 1-10 indicator
- Light off: Link is disconnected
- Red light on: Powering but data disconnected
- Light flash quickly: Data Transmitting
- PoE Ports
- 8, 1000Mbps; RJ45 ports; Max. 30W Output of Single PoE Port Transmission distance: 0~100
- Network Port
- 10
- MAC Address Table
- 2K
- PoE Standard
- IEEE802.3af, IEEE802.3at
- PoE Power Supply
- 1/2(+), 3/6(-)
- Transmission Distance
- 0-100m/100 Mbps
- PoE Power Budget
- 96W
- Power Indicator
- Light on: Powering; Light off: No Power
- PoE Feature
- All ports support MDI/MDIX
- ESD
- Air discharge: 1.5KV ; Contact discharge: 1.5KV
- VLAN
- Support
- VLAN Indicator
- Green light on: VLAN mode Light off: normal mode
- Watchdog
- Support
- Forwarding Mode
- Store-and-forward
- Power Source
- Built-in Power Supply, Input: 110-264V AC, 50/60Hz
- Power Consumption
- <5W
- Operating Temperature
- -10°C~-50°C
- Storage Temperature
- -40°C~70°C
- Anti-thunder Level
- Common mode: 2KV ; Differential mode: 2KV
- Humidity
- 10%-95% , non-condensing
- Dimensions
- 202mm x 140mm x 45mm
- Color
- Black
- Weight
- 0.9Kg (not include input cable & packaging)
