16, 10/100Mbps; RJ45 ports; Max. 30W Output of Single PoE Port
IEEE802.3/802.3u/802.3ab/802.3z/802.3x
1000Mbps or Max. 250m/10Mbps;Transmission Distance: 0-100m
Support ESD and Surge Protection
- Easy and safe installation
- wall-mounting, desktop,Kensington security slot, Plug-and-play.
- Uplink Ports
- 2 Ports 1000Mbps RJ45 uplink ports + 1 Port 1000Mbps SFP port
- Network Standard
- IEEE802.3/802.3u/802.3ab/802.3z/802.3x
- Switch Capacity
- 92 Gbps Full duplex
- Packet Forwarding Rate
- IEEE802.3/802.3u/802.3ab/802.3z/802.3x
- PoE Ports
- 16, 10/100Mbps; RJ45 ports; Max. 30W Output of Single PoE Port
- Network Port
- 19
- Transmission Distance
- 0-100Mtr./1000Mbps or Max. 250Mtr./10Mbps via Cat.5e or more under Extend mode
- MAC Address List
- 4K
- PoE Standard
- IEEE802.3af, IEEE802.3at
- Packet Buffer
- 1.5Mb
- Backplane Bandwidth
- 5.6Gbps
- CCTV Mode
- Downlink ports only communicate with uplink ports , Restrain network storm under 2Mbps , Extend transmission distance to 250m , Rate:10Mbps(Downlink Ports)
- Data Package Cache
- 2. 75Mb
- Downlink Ports
- 8x10/100/1000Base-T Ethernet Ports(PoE)
- ESD
- Contact Discharge 6KV , Air Discharge Level 8KV , Standard: IEC61000-4-2
- ESD Protection
- Contact discharge 6K, Air discharge 8KV, Per: IEC61000-4-2
- Ethernet Port Light
- 2pcs(Yellow&Green) on RJ45 yellow indicates PoE, green indicates Link Act
- Exchange Capacity
- storage&Fowarding
- Exchange Type
- Storage & Fowarding
- LED light
- Red means recording, yellow means audio recording, Green means standby.
- Lightning Protection
- 6KV Per: IEC6 1 000-4-5
- PoE Power Budget
- 12W
- PoE Power Supply
- 1/2(+),3/6(-)
- Port Parameter Rate
- 1~8 Downlink Ethernet port:10/100Mbps , 9~10uplink Ethernet port:10/100/1000Mbps
- Power Light
- 1x Red LED
- Single Port Power Output& Voltage
- single Port PoE Power Output=30W, Voltage 54VDC
- Surge Immunity
- 6KV
- Surveillance Module Light
- 1pc(Green), green indicates CCTV
- Switch Capacity
- 20Gbps
- Transmission Distance
- 100m(Max.)
- Uplink Ports
- 1x 10/100/1000Base-TEthernet Ports & 1x 1000Base-X SFP Port
