2+2 Output Terminals for Easy Installation
Short Circuit, Over Voltage and Over Current Protection
AC I/P & DC O/P Terminals are Covered for Safety
Power On Indicator
Cable Compensation Switch
Built-in EMI Filter to Nullify Interference
100% Full Load Burn-in Test
Cooling by Free Air Convection
Shock Proof Plastic Housing
Wall Mount Option Along with Desktop
- Input voltage
- 200 ~ 240VAC
- Input AC Frequency Range
- 47 ~ 63Hz
- Input Current (Typ.)
- 1A/230VAC
- Power Cord
- 2 Pin (L & N)
- Standby Power Consumption
- ≤0.5W
- Inrush Current (Typ.)
- ≤40A@230VAC
- Efficiency (Typ.)
- 85%
- Output voltage
- Normal Mode 12V
- Output Current range
- Normal Mode 0 ~ 5.0A
- Rated Power
- Normal Mode 60W
- Ripple & Noise (max.)
- ≤240mV
- Line Regulation
- 2%
- Load Regulation
- 3%
- Power On Indicator
- Support
- Cable Compensation Switch
- Support, 3 Modes (Normal, Long, Ex. Long)
- No. of Output Ports
- 2 output terminals
- short-circuit protection
- Support
- Dielectric Strength (Hi-pot)
- 3.0KV
- Insulation Resistance
- 100MΩ@500VDC
- Surge Immunity
- 1.0KV
- Operating Temperature
- -10 ~ +45°C
- Operating Humidity
- 20 ~ 90% RH Non-condensing
- Storage Temperature
- -10 ~ +45°C
- Storage Humidity
- 10 ~ 95% RH
- Dimension
- 141.5mm x 102.6mm x 33.2mm
- Weight
- 0.234kg without Power Cord and Packing Box
