Color-coded Fibers ensure easy identification
Comes with UV-protected HDPE outer sheath
Offers low signal loss during transmission
Withstands up to 1000 N tensile force
4 Optical Fibers enclosed in a single robust sheath
Operates reliably from –20°C to +70°C
- Cable Bending Radius
- Long Term 20 x Cable Diameter, Short term 10 x Cable Diameter
- Tensile
- Short Term 1000 N, Long Term 500 N
- Single Mode Optical Fiber
- Attenuation at 1310 nm: < 0.35 dB/Km Attenuation at 1550 nm: < 0.25 dB/Km
- Colour Code
- Color of Fibers in a Tube: Blue, Orange, Green, Brown, Slate, White, Red, Black, Yellow, Violet,Pink, Nat Color of Loose Tubes: Natural
- Cable Constructional
- a) Primary Coated Fiber: Single Mode - G 652 b) Tube Filling Compound: Thixotropic Jelly c) Loose Tube (s): PBTP d) Strength Member: FRP Rod e) Armour: Corrugated ECCS Tape f) Outer Sheath ( T= 1.8 mm Nominal): UV protected Black HDPE
- Laying and Installation Temperature
- -20°C to +70°C
- Operating Temperature
- -20°C to +70°C
- Transport and Storage Temperature
- -20°C to +70°C
- Nominal Cable Weight
- 42 ± 2
- Nominal Cable Diameter
- 7.5 ± 0.2
- Standard Length
- 1000 ± 10 % (per Drum Mtr.)
