Conforms to TIA /EIA- 568-C.2
Excellent Margin with suppression of Cross Talk (NEXT)
2 conductors twisted together to form a pair
10 Mtr. Standard Cable Length
4 Pairs are laid up and separated from one another through a Cross Separator
Laid up of 4 Pairs is sheathed with PVC
- Conduct Type
- Stranded Bare Electrolytic Grade Copper
- Nominal Conductor Diameter
- 24AWG (7/0.195 ± 0.010)
- Insulation
- Polyethylene (HDPE)
- No. of Pair
- 4, Each pair Twisted
- Pairing
- Twisted into Two core
- Connector Type
- UTP RJ-45 3Part Connector both ends
- Outer Sheath Material
- PVC
- Colour of Sheath
- Grey
- Approximate OD
- 5.90mm ± 0.20mm
- Cable Skew
- Max. 45 (ns/100 Mtr.)
- Conductor Resistance
- Max. 98 @20°C
- Sequential Marking
- At Every Meter
- Standard Length
- 10 Mtr.
- Temperature Rating
- -15°C to +70°C
- Capacitance Unbalance
- Max. 330 (pf/100 Mtr.)
- Velocity of Propagation
- 69%
- Mutual Capacitance
- Max. 5.6 (nf/100 Mtr.)
