EMC/EMI Standards
ABS , Fire protection
Over Current/Voltage Protection; Short Circuit Protection; Over load protection
LED indicator for power on
For India Market Only
- Input voltage
- 150VAC - 240VAC
- Output Connector
- Terminal Block Type
- Output voltage
- 12V DC
- Current Range
- 0-1A Each Channel
- Voltage Adj. Range
- 12V DC - 15V D
- Ripple & Noise (max.)
- <200mV
- Rated Power
- 48W
- Voltage Tolerance
- 10%
- Line Regulation
- <3% at 150Vac-240Vac
- Linear modulate
- SMPS (Switch mode power supply)
- Load Regulation
- <10% at 150VAC-240VAC
- Setup Rise time
- 30mS max @ rated load, output voltage from 10% to 90%.
- Hold Up Time (Typ.)
- 30ms max @ full load & 230Vac input turn of
- Temperature coefficient
- Max 75 degree
- start time
- 30mS max @ rated load, output voltage from 10% to 90%.
- Frequency Range
- 50Hz-60Hz. Normal
- Efficiency (Typ.)
- 70%
- AC Current (Typ.)
- 1.2A Max @ max 100-240VAC Input & full load
- guard time
- MAX 2Sec@ 150-240VAC at Input & full load
- override protection
- Supported
- Inrush Current (Typ.)
- 50A max @ 240 Vac input & full load
- Leakage Current
- 0.008 A Max.
- Over Voltage Protection
- Supported
- short-circuit protection
- Supported (AUTO RECOVERY)
- Over Load
- Supported
- Withstand Voltage
- Input (100 - 240)V AC/ Output (12 -15)V DC
- Isolation Resistance
- 50MΩ min at primary to secondary add 500Vdc test voltage
- Over Current
- Supported
- Working temperature
- -10°C to +45°C
- Store temperature
- -40°C to +70°C
- Weight
- 233.1gm
- Working Humidity
- 5% to 95%
- Dimension
- 154.7mm x 97.38mm x 32.90mm
- Body Type
- Plastics ABS
