3.5 inch LCD with an interactive, user-friendly interface.
Monitor and display the real-time signal strength of environmental interference.
Automatically searches operating frequency (20 levels available).
Counting passing number, pass/return numbers, and alarm number.
Pass/Return statistics, alarm statistics, and searching by day.
Safe low-voltage design.
Reliable and stable aviation connector.
9 alarm tones with 10 adjustable volume levels, mute mode and alarm duration: 0–10 s.
255 adjustable sensitivity levels
Separate parameter configuration for 12 supported scenarios.
IR remote controller
Multiple IR detection modes.
Supports lead-acid batteries (optional).
Easy-to-install modular design.
- Minimum detect target
- One coin.
- Precise Positioning
- 6 overlapping detection zones, bilateral transmission and receipt of detection signals, 1 panel indicator lights
- Zone Indication
- 6 independent zones, and multiple metal items can be located simultaneously
- IR Sensor
- Infrared sensor can reduce false alarms; automatic alarm statistics and pass/return statistics
- Adjustable Sensitivity
- 255 adjustable sensitivity levels in each detection zone (sensitivity increases by levels)
- Remote Control
- Comes with a infrared remote controller with the maximum remote control range of 2m (6.56ft)
- Leakage Current
- < 0.5 mA, complying with safety requirements for electronic devices
- Operating Voltage
- 12 V DC, power adapter (included): 100 V–240 V AC, 50/60 Hz
- Maximum Power Consumption
- 11 W
- Typical Power Consumption
- 7.8W
- Power Output
- 12V DC
- Operating Temperature
- -20 °C to +65 °C (–4 °F to +149 °F)
- Operating Humidity
- 0%–95% (RH), non-condensing
- Storage Temperature
- -20 °C to +65 °C (–4 °F to +149 °F)
- Storage Humidity
- 0%–95% (RH), non-condensing
- Power Button
- Power switch on both door panels, and metal detection power switch on the front panel
- Indicator Light
- One green indicator
- Environmental Noise
- Monitors and displays real-time signal strength of environmental interferences
- Installation
- Vertical mounting
- Passageway Interior Size
- 2003 mm x 720 mm x 393 mm (87.0
- Overall Exterior Size
- Bare: 2208 mm × 866 mm × 488 mm (86.93
- Packing Size
- 2271 mm × 695 mm × 215 mm (89.41
- Gross Weight
- 47Kg
