1/3" 2.4MP PS CMOS Image Sensor (0.84667 centimeters)
Max. 2.4MP (1920×1080)@30fps
DWDR, Day/Night (ICR), 3D NR, BLC, HLC
3.6mm Lens (2.8 mm optional)
IR Range of 30 Mtrs., Smart IR, Smart Dual Light
Support Built-in Mic & Speaker
Support Two-way Talk*, IP67
- Image Sensor
- 1/3
- Effective Pixels
- 1920 (H) × 1080 (V)
- Resolution
- 2MP (1920 × 1080), 960H (960 × 576/ 960 × 480)
- Shutter Speed
- PAL: 1/25 s–1/100000 s, NTSC: 1/30 s–1/100000 s
- Minimum Illumination
- 0.01 lux@F2.0 (Color, 30 IRE), 0.01 lux@F2.0 (B/W, 30 IRE), 0 lux (IR on)
- IR Control
- Auto, Manual
- Angle Adjustment
- Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°
- Max. Aperture
- F2.0
- Lens Type
- Fixed-focal
- Lens Mount
- M12
- Lens
- 3.6mm Lens (2.8mm Optional)
- Close Focus Distance
- 3.6 mm: 0.7 m; 2.8 mm: 0.5 m
- IR Number
- 2 (Multi-core light)
- IR
- IR Range of 30 Mtr.
- IR Mode
- Smart IR&WL, WL Mode, IR
- Gain Control (AGC)
- Auto, Manual
- Frame Rate
- CVI: PAL: 1080p@25 fps, NTSC: 1080p@30 fps
- AHD: PAL: 1080p@25 fps, NTSC: 1080p@30 fps
- TVI: PAL: 1080p@25 fps, NTSC: 1080p@30 fps
- CVBS: PAL: 960H, NTSC: 960H
- Day/Night
- Auto(ICR)/Color/B/W
- Back Light Compensation
- BLC/ HLC/ DWDR
- Angle of View
- 3.6 mm: H: 89°, V: 48.2°, D: 109.1°; 2.8 mm: H: 111.3°, V: 60.8°, D: 134.2°
- Audio
- Built-in Mic, up to 8 Mtr.
- Power Source
- 12 VDC (±30%) (It is recommended to use a power adapter to supply the power for one camera)
- Power Consumption
- Max 6.6 W (12 VDC, IR on)
- Operating Temperature
- –30 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity
- <95% (RH), non-condensing
- Storage Humidity
- <95% (RH), non-condensing
- Casing
- Plastic
- Dimension
- 161.6 mm × 69.7 mm × 70.0 mm (L × W × H)
