1/2.8” 2MP PS CMOS Image Sensor (0.9071 centimeter)
1920(H) × 1080(V) @25/30 fps.
C/CS Mount Lens
Instastream, H.265, H.264+, H.264, H.264B, H.264H, MJPEG
Support Quad Stream
WDR(120dB), ICR, 3D DNR, Defog, ROI, EIS, AWB, AGC, BLC, HLC
Support Micro SD Card, Digital Watermarking, Built-in Mic, PoE
- Image Sensor
- 1/2.8” 2MP PS CMOS Image Sensor (0.9071 centimeter)
- Minimum Illumination
- Colour Mode 0.0021 Lux @F1.6, Night Mode (Black & White) 0.00021Lux @F1.6
- Effective Pixels
- 1920 (H) × 1080 (V)
- Shutter Speed
- Auto/Manual, 1/3 s–1/100000 s
- RAM
- 512 MB
- ROM
- 512 MB
- White Balance
- Auto/Natural/Street Lamp/Outdoor/Manual
- Lens Mount
- C/CS
- Gain Control (AGC)
- Auto
- Back Light Compensation
- BLC / HLC / WDR(120dB)
- stream Capability
- Quad Stream
- Video Format
- PAL/NTSC
- Video Compression
- Instastream, H.265, H.264+, H.264, H.264B, H.264H, MJPEG (only supported by sub stream)
- Resolution
- 2MP(1920 × 1080) / 1.3M (1280 × 960) / 1MP(1280 × 720) / D1 (704 × 576 / 704 × 480) / VGA (640 × 480) / CIF (352 × 288 / 352 × 240)
- Bit Rate Control
- CBR/VBR
- Bit Rate
- H.264: 3 kbps–6144 kbps, H.265: 3 kbps–6144 kbps
- Noise Reduction
- 3D DNR
- Image Stabilization
- Electronic Image Stabilization (EIS)
- Motion Detection
- OFF/ON (8 Areas, Rectangular)
- Two-way Talk
- Support
- Audio Input
- 1 Channel
- Alarm IN
- 2 channels: 5 mA 3–5 VDC
- Alarm Out
- 2 channels: 1,000 mA 30 VDC/500 mA 50 VAC
- OSD
- Camera title, Date & Time
- Protocol
- IPv4, IPv6, HTTP, HTTPS, ARP, RTSPS, SMTP, SFTP, DHCP, DNS, UPnP, NTP, Multicast, NFS, PPPoE, SNMP V1/V2/V3, ICMP,IGMP, ONVIF (Profile S, Profile G, Profile T), Unicast, Multicast
- IVS (Optional)
- Tripwire, Intrusion, Object Abandon/ Missing, IMD (Intelligent motion detection), Face Detection
- Audio Compression
- PCM, G.711a, G.711Mu, G.726, MPEG2-Layer2, G.722
- Ethernet
- RJ-45 (10/100Base-T)
- Day/Night
- Auto(ICR)/ Color/ B/W
- User/ Host
- 20 (Total bandwidth: 80 M)
- Browser
- Microsoft Edge and Chrome
- Storage
- SFTP, NAS, Micro SD card (support max. 512 GB)
- Frame Rate
- Main stream: 2MP/1.3MP/1MP/D1@(1-25/30fps) Sub stream 1: D1/VGA/CIF@(1-25/30fps) Sub stream 2: 2MP/1.3MP/1MP/D1@(1-25/30fps) Sub stream 3: D1/VGA/CIF@(1-25/30fps)
- Flip
- 0°/90°/180°/270°
- Certificates
- MTBF Certificate from STQC, EMI/EMC, ISO9001, CE, FCC and RoHS, BIS, STQC approved compliance report
- Power Source
- DC 12V (±30%), AC 24V (±30%), PoE
- Power Out
- 12 VDC power output, max. current 165 mA, peak current 700 mA
- Power Consumption
- <10W
- Operating Temperature
- -30° C to +60° C
- Operating Humidity
- ≤95% RH, Non condensing
- Storage Temperature
- -30° C to +60° C
- Dimension
- 161.6mm × 86.8mm × 74.0mm
- Weight
- 0.8kg
