1/2.8ā 4MP PS CMOS Image Sensor (0.9071 centimeters)
Max. 4MP (2688 x 1520)@45fps
Instastream, H.265, H.264+, H.264
Support Triple Stream
WDR(120dB), Day/Night (ICR), 3D DNR, ROI, AWB, AGC, HLC, BLC
3.6mm fixed Lens
IR Range of 30 Mtr.
Micro SD Card, IP67, IK10, PoE
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite, EVMS Pro
- Image Sensor
- 1/2.8ā 4MP PS CMOS Image Sensor (0.9071 centimeters)
- Minimum Illumination
- 0.006 lux@F1.6 (Color, 30 IRE); 0.0006 lux@F1.6 (B/W, 30 IRE); 0 lux (Illuminator on)
- Max. Resolution
- 2688(H) x1520(V)
- Electronic Shutter
- Auto/Manual 1/3 s-1/100000 s
- Angle Adjustment
- Pan: 0Ā°ā20Ė, Tilt: 0Ā°ā15Ė, Rotation: 0Ā°ā360Ė
- ROM
- 256 MB
- RAM
- 256 MB
- White Balance
- Auto, Natural, Street lamp, Outdoor, Manual, Custom Area
- DORI Distance
- 77.8 Mtr. (Detect), 31.1 Mtr.(Observe), 15.6 Mtr.(Recognize), 7.8 Mtr(Identify)
- Gain Control(AGC)
- Auto/Manual
- Lens Type
- Fixed-focal
- Max. Aperture
- F1.6
- Close Focus Distance
- 1.5m
- Lens
- 3.6mm fixed Lens
- Lens Mount
- M14
- Video Compression
- Instastream, H.265, H.264+, H.264
- Angle of view
- Horizontal: 82.7Ā°, Vertical: 45.3Ā°, Diagonal: 96.6Ā°
- Back Light Compensation
- BLC/ HLC/ WDR(120dB)
- Resolution
- 4MP (2688 Ć 1520), 3MP (2304 Ć 1296), 2MP (1920 Ć 1080), 1.3MP (1280 Ć 960), 1080P (1920Ć 1080 ), 720p (1280 Ć 720), D1 (704 Ć 576), VGA (640 Ć 480), CIF (352 Ć 288) ,QVGA (320 Ć 240)
- Stream Capability
- Triple Stream
- Frame Rate
- Main Stream: 4MP (2688 Ć 1520)@45fps, 3MP (2304 Ć 1296)@45fps, 2MP (1920 Ć 1080) @45fps, 1.3MP (1280 Ć 960)@45fps, 720p (1280 Ć 720)@45fps Sub Stream 1: 2MP (1920 Ć 1080)@25/30fps, D1 (704 Ć 576)@25/30fps, VGA (640 Ć 480) @25/30fps, CIF (352 Ć 288)/ (352x240)@25/30fps Sub Stream 2: VGA (640 Ć 480)@25/30fps, CIF (352 Ć 288)/ (352x240)@25/30fps,QVGA (320 Ć 240)@25/30fps
- Day/Night
- Auto(ICR)/Color/B/W
- Motion Detection
- OFF/ON (4 areas, rectangular)
- Bit Rate Control
- CBR/VBR
- Bit Rate
- H.265: 3- 8192Kb/s, H.264:3- 8192Kb/s
- Protocol
- IPv4, IPv6, HTTP, HTTPS, TCP, UDP, RTP, RTSP, RTCP, RTMP, 802.1x, SMTP, SFTP, DHCP, DNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NAS, PPPoE, SNMP v3, Auto Connect, TLS v1.2 and v1.3, ONVIF (Profile S, Profile G, Profile T), InstaOn
- Device Search Tool
- IP finder
- Event Alarm
- Motion Detection, Video Tampering, Scene Changing
- Smart IR
- Support
- Image Rotation
- 0Ā°/90Ā°/180Ā°/270Ā°
- IR Number
- 2 IR
- IR
- IR Range of 30 Mtr.
- Browser
- Edge, Chrome, Firefox, Safari
- Iris Control
- Fixed
- IR Control
- Auto, Manual
- Storage
- FTP, SD Card 128GB
- Ethernet
- M12 D-Coding(10/100Base-T)
- User/ Host
- Unicast: 10 Users, Multicast: 20 Users
- Certificates
- ISO 9001: 2015, ISO 20000-1 : 2018, ISO 14001 : 2015, ISO 45001 : 2018, ISO 50001:2018, CE, FCC and RoHS, BIS, STQC approved compliance report, IP67 & IK10, Environment, EMI EMC, MTBF certificates
- Power Source
- POE (802.3af)
- Power Consumption
- < 7.1W
- Weatherproof Standard
- IP67, IK10
- Reset Button
- Support
- Operating Humidity
- Less than 95% RH
- Storage Temperature
- -40Ā°C - +70Ā°C
- Storage Humidity
- Less than 95% RH
- Dimensions
- 140.6 mm Ć 112.9 mm Ć 69.4 mm
- Weight
- 590g
