English
1/2.9” 4MP PS CMOS Image Sensor (0.8758 centimeters)
Max. 4MP (2688 × 1520)@1-25/30fps/ (2560 × 1440)@1-25/30
Instastream, H.265, H.264, H.264H, H.264B, MJPEG
Support Triple stream
WDR (120dB), Day/Night(ICR), 3D NR, ROI, AWB, AGC, BLC, HLC, Digital watermarking
IR Range of 30 Mtr., Warm Light Range of 30 Mtr.
3.6mm fixed Lens
Support Built-in Mic, PoE,
- Image Sensor
- 1/2.9
- Effective Pixels
- 2688 (H) × 1520 (V)
- Minimum Illumination
- 0.06 lux@F1.6 (Color, 30 IRE), 0.006 lux@F1.6 (B/W, 30 IRE), 0 lux (IR on)
- Angle Adjustment
- Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°
- Shutter Speed
- Auto/Manual 1/3 s–1/100,000 s
- White Balance
- Auto, Natural, Street lamp, Outdoor, Manual, Regional custom
- ROM
- 128 MB
- DORI Distance
- Lens 3.6 mm: 85.4 m (Detect), 34.2 m (Observe), 17.1 m (Recognize), 8.5 m (Identify)
- Gain Control (AGC)
- Auto/ Manual
- Lens Type
- Fixed-focal
- Lens Mount
- M12
- Lens
- 3.6mm fixed Lens
- IR Number
- 1 (Multi-core (IR + warm) light)
- IR
- IR Range of 30 Mtr.
- Smart Illumination
- Support
- IR Control
- Auto, Manual
- Angle of view
- 3.6 mm: H: 78°, V: 40°, D: 93°
- Back Light Compensation
- BLC/ HLC/ WDR(120dB)
- Resolution
- 4MP (2688 x 1520)/ (2560 × 1440), 3MP (2304 × 1296), 2MP (1920 × 1080), 1.3MP (1280 × 960), 720p (1280 × 720), D1 (704 × 576 / 704 × 480), VGA (640 × 480), CIF (352 × 288 / 352 × 240)
- Video Compression
- Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by sub stream)
- Noise Reduction
- 2D NR
- Motion Detection
- OFF/ON
- Video Format
- PAL/NTSC
- Stream Capability
- Triple stream
- Frame Rate
- Main stream: 4MP (2688 × 1520)@1-25/30fps/ (2560 × 1440)@1-25/30 Sub stream 1: 720P( 1280 × 720), D1 (704 × 576)@1–25 fps/ (704 × 480)@1–30 fps, VGA(640 × 480)@1-30fps, CIF (352 × 240)@1-30fps, (352 × 288) @1-25fps Sub stream 2: D1 (704 × 576)@1–25 fps/ (704 × 480)@1–30 fps, VGA(640 × 480)@1-30fps, CIF (352 × 240)@1-30fps/ (352 × 288) @1-25fps
- Privacy Mask
- 8 areas
- OSD
- Camera title, Date & Time
- Audio Compression
- G.711a, G.711Mu, PCM, G.726, AA
- Bit Rate Control
- CBR/ VBR
- Bit Rate
- H.265: 3 kbps-6144 kbps, H.264: 8 kbps-6144 kbps
- Protocol
- IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T), unicast, multicast
- Day/Night
- Auto(ICR)/Color/B/W
- Ethernet
- RJ-45 (10/100 Base-T)
- Smart IR
- Support
- Image Rotation
- 4MP only support 0°/180° 2MP & lower will support 0°/90°180°/270°
- User/Host
- 6 (Total bandwidth: 36 M)
- Browser
- IE, Chrome, Firefox
- Iris Control
- Fixed
- Certificates
- ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report
- Power Source
- 12 VDC/ PoE (802.3af)
- Power Consumption
- Basic: 1.6 W (12 VDC), 2.0 W (PoE); Max. : 3.7 W (12 VDC), 4.7 W (PoE) (H.265 + intelligence on + WDR+ warm light intensity
- Operating Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity
- ≤95%(RH), non-condensing
- Storage Humidity
- ≤95%(RH), non-condensing
- Dimensions
- 162.6 mm × 70 mm× 70 mm
- Weight
- 220g
