1/2.8" 4MP PS CMOS Image Sensor (0.9071 centimeters)
Max. 4MP (2688 × 1520)@1-30fps/ 4MP (2560 × 1440)@1-25/30
Instastream, H.265, H.264, H.264H, H.264B, MJPEG
Support Triple stream
WDR(120dB), Day/Night(ICR), 3D NR, AWB, AGC, BLC, HLC
6mm Fixed Lens
Support Built-in Mic
IR Range of 60 Mtr., IP67, PoE
- Image Sensor
- 1/2.8" 4MP PS CMOS Image Sensor (0.9071 centimeters)
- Minimum Illumination
- 0.001 lux@F1.4 (Color, 30 IRE), 0.0001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on)
- Effective Pixels
- 2688 (H) × 1520 (V)
- Angle Adjustment
- Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°
- Shutter Speed
- Auto/Manual 1/3 s–1/100,000 s
- White Balance
- Auto, Natural, Street lamp, Outdoor, Manual, Regional custom
- RAM
- 128 MB
- ROM
- 128 MB
- Close Focus Distance
- 3.2 m
- Gain Control(AGC)
- Auto, Manual
- Lens Type
- Fixed-focal
- Max. Aperture
- F1.4
- Lens Mount
- M12
- DORI Distance
- 124.0 m (Detect), 49.6 m (Observe), 24.8 m (Recognize), 12.4 m (Identify)
- Video Format
- PAL/NTSC
- OSD
- Camera title, Date & Time
- Lens
- 6mm Fixed Lens
- Angle of view
- H: 49°, V: 26°, D: 57°
- S/N Ratio
- >58dB
- Video Compression
- Instastream, H.265, H.264, H.264H, H.264B, MJPEG (only supported by the sub stream)
- Back Light Compensation
- BLC/ HLC/ WDR (120dB)
- Day/Night
- Auto(ICR)/Color/B/W
- IR Number
- 4 IR LED
- IR
- IR Range of 60 Mtr.
- Smart IR
- Support
- Resolution
- 4MP (2688 x 1520)/ (2560 × 1440), 3MP (2304 × 1296), 2MP (1920 × 1080), 1.3MP (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240)
- stream Capability
- Triple stream
- Frame Rate
- Main stream: 4MP (2688 × 1520)@1-25/30fps, 4MP (2560 × 1440)@1-25/30 Sub stream 1: 720P( 1280 × 720) D1 (704 × 576)@1–25 fps/ (704 × 480)@1–30 fps, VGA(640 × 480)@1-30fps, CIF (352 × 240)@1-30fps, (352 × 288) @1-25fps Sub stream 2: D1 (704 × 576)@1–25 fps/ (704 × 480)@1–30 fps, VGA(640 × 480)@1-30fps, CIF (352 × 240)@1-30fps/ (352 × 288) @1-25fps
- Motion Detection
- OFF/ON (4 areas, rectangular)
- Privacy Mask
- 4 areas
- ROI
- Support (4 Areas)
- Audio Compression
- G.711a, G.711Mu, PCM, G.726, AAC
- Mirror Function
- Support
- Audio
- Built-In Mic
- Bit Rate
- H.265: 3 kbps-6144 kbps, H.264: 8 kbps-6144 kbps
- Bit Rate Control
- CBR/VBR
- Human body Detection
- Support the classification and accurate detection of human
- Protocol
- SFTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T), unicast, multicast
- Noise Reduction
- 3D NR
- Ethernet
- RJ-45 (10/100 Base-T)
- SDK and API
- Support
- Alarm Event
- Network disconnection, IP conflict, illegal access, Motion detection, Video tampering, Audio detection, IMD (Intelligent motion detection), Security exception
- Cyber Security
- AES 256-bit Encryption, Configuration encryption, trusted execution, Digest, security logs, WSSE, account lockout, syslog, video encryption, IP/MAC filtering, HTTPS, trusted upgrade, trusted boot
- Browser
- IE, Chrome, Firefox
- IR Control
- Auto, Manual
- Image Rotation
- 4MP only support 0°/180° 1080P & lower will support 0°/90°180°/270°
- Smart search
- Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
- Iris Control
- Fixed
- User/Host
- 6 (Total bandwidth: 36 M)
- Weatherproof Standard
- IP67
- Certificates
- ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report
- Power Source
- 12 VDC/PoE (802.3af)
- Power Consumption
- Basic: 2 W (12 VDC); 2.9 W (PoE) Max. (H.265 + intelligence on+ WDR + illuminator intensity): 5.3W (12 VDC), 6.8 W (PoE)
- Operating Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity
- ≤95%
- Storage Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity
- ≤95%
- Casing
- Metal + Plastic
- Dimension
- 197.9 mm × 80.2 mm × 76.2 mm
- Weight
- 310 g
