1/2.7" 2MP PS CMOS Image Sensor (0.9407 Centimeters)
Max. 2MP (1920 × 1080)@1–25/30fps
Instastream, H.265, H.264, H.264H, H.264B, MJPEG
Support Quad stream
WDR(120dB), Day/Night(ICR), 3D NR, ROI, AWB, AGC, BLC, HLC, Digital watermarking
IR Range of 50 Mtr., Warm Light Range of 50 Mtr.
3.6mm fixed Lens
Micro SD Card, PoE, IP67, IK10 (optional)
- Image Sensor
- 1/2.7
- Effective Pixels
- 1920 (H) × 1080 (V)
- Minimum Illumination
- 0.001 lux@F1.4 (Color, 30 IRE), 0.001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on)
- Shutter Speed
- Auto/Manual 1/3 s–1/100,000 s
- Angle Adjustment
- Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°
- White Balance
- Auto, Natural, Street lamp, Outdoor, Manual, Regional custom
- RAM
- 128 MB
- ROM
- 128 MB
- DORI Distance
- Lens 3.6 mm: 58.9 m (Detect), 23.6 m (Observe), 11.8 m (Recognize), 5.9 m (Identify)
- Gain Control(AGC)
- Auto/ Manual
- Lens Type
- Fixed-focal
- Close Focus Distance
- 1.3 m
- Lens
- 3.6mm fixed Lens
- Lens Mount
- M12
- S/N Ratio
- >56 dB
- Back Light Compensation
- BLC/ HLC/ WDR(120dB)
- Angle of view
- 3.6 mm: H: 84°, V: 44°, D: 105°
- Video Compression
- Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by sub stream)
- IR Number
- 2 IR LED, 2 Warm Light
- IR
- IR Range of 50 Mtr.
- IR Control
- Auto, Manual
- Frame Rate
- Main stream: 2MP (1920 × 1080)@1–25/30 fps Sub stream 1: 720P@1–25/30 fps Sub stream 2: D1@1–25/30 fps Sub stream 3: D1@1fps
- Video Format
- PAL/NTSC
- Privacy Mask
- 8 areas
- Audio Input
- 1 Channel (RCA port)
- Audio Output
- 1 Channel (RCA port)
- OSD
- Camera title, Date & Time
- Audio Compression
- G.711a, G.711Mu, G.726, PCM, AAC
- Alarm Out
- 1 Channel out: 300 mA 12 VDC
- Bit Rate
- H.265: 3 kbps-6144 kbps, H.264: 8 kbps-6144 kbps
- Bit Rate Control
- CBR/ VBR
- Protocol
- FTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T), unicast, multicast
- SDK and API
- Support
- Ethernet
- RJ-45 (10/100 Base-T)
- Browser
- IE, Chrome, Firefox
- Mirror Function
- Support
- Resolution
- 2M (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240)
- Noise Reduction
- 2D NR
- Storage
- FTP, Mirco SD card (Max. 512GB)
- Iris Control
- Fixed
- Image Rotation
- 0°/90°/180°/270° (Support 90°/270° with 2M resolution and lower)
- User/Host
- 6 (Total bandwidth: 36 M)
- Certificates
- ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report
- Power Source
- 12 VDC/PoE (802.3af)
- Power Consumption
- Basic: 1.6 W (12 VDC), 2.1 W (PoE) Max. (H.265+ intelligence on + WDR + illuminator on): 5.8 W (12 VDC), 6.9 W (PoE)
- Weatherproof Standard
- IP67 & IK10
- Operating Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity
- ≤95%
- Storage Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity
- ≤95%
- Dimensions
- 238.5 mm × 90.7 mm × 90.7 mm
- Weight
- 720g
