English
1/2.7” 8MP PS CMOS Image Sensor (0.9407 centimeters)
Max. 8MP (3840 × 2160)@1–20 fps
Instastream, H.265, H.264,H.264H, H.264B, MJPEG
Support Quad Stream
WDR(120dB), Day/Night(ICR), 2D NR, 3D NR, ROI, AWB, AGC, BLC, HLC, Digital watermarking
IR Range of 50 Mtr., Warm Light Range of 30 Mtr.
3.6mm Lens
Support Starlight Technology
Micro SD Card, PoE, IP67, IK10 (optional)
- Image Sensor
- 1/2.7” 8MP PS CMOS Image Sensor (0.9407 centimeters)
- Effective Pixels
- 3840 (H) × 2160 (V)
- Minimum Illumination
- 0.001 lux@F1.4 (Color, 30 IRE), 0.0001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on)
- Angle Adjustment
- Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°
- Shutter Speed
- Auto/Manual 1/3 s–1/100,000 s
- White Balance
- Auto, Natural, Street lamp, Outdoor, Manual, Regional custom
- RAM
- 256 MB
- ROM
- 128 MB
- DORI Distance
- 98.7 m (Detect), 39.5 m (Observe), 19.7 m (Recognize), 9.9 m (Identify)
- Gain Control(AGC)
- Auto/ Manual
- Lens Type
- Fixed-focal
- Max. Aperture
- F1.4
- Close Focus Distance
- 1.9 m
- Smart IR
- Support
- IR Number
- 2 IR LED, 2 Warm Light
- IR
- IR Range of 50 Mtr.
- Warm Light
- Warm Light Range of 30 Mtr.
- IR Control
- Auto, Manual
- Iris Control
- Fixed
- Lens
- 3.6mm
- Lens Mount
- M12
- S/N Ratio
- >58 dB
- Back Light Compensation
- BLC/ HLC/ WDR(120dB)
- Angle of view
- H: 87°, V: 49°, D: 100°
- Day/Night
- Auto(ICR)/Color/B/W
- OTA (Over-The-Air)
- Support
- Stream Capability
- Quad Stream
- Frame Rate
- Main stream: 8MP (3840 × 2160)@1–20 fps/ 4MP (2688 × 1520)@1–25/30 fps Sub stream 1: D1@(1–25/30 fps) Sub stream 2:D1@(1–25/30 fps) Sub stream 3:D1@1fps
- Audio
- Built-in Mic
- Video Compression
- Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by sub stream)
- IVS (Perimeter Protection)
- Intrusion, Tripwire (the two functions support the classification and accurate detection of vehicle and human)
- Video Format
- PAL/NTSC
- Smart search
- Work together with AI NVR to perform refine AI search, event extraction and merging to event videos
- Resolution
- 8MP (3840 × 2160), 6MP (3072 × 2048), 5MP (3072 × 1728), 4.5MP (2880 × 1620), 4MP (2688 × 1520), 3MP (2048 × 1536), (2304 × 1296), 2MP (1920 × 1080), 1.3MP (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 ×480), VGA (640 ×480), CIF (352 × 288/352 × 240)
- Noise Reduction
- 2D NR, 3D NR
- Motion Detection
- OFF/ON (4 areas, rectangular)
- Privacy Mask
- 4 areas
- ROI
- Support (4 areas)
- Mirror Function
- Support
- OSD
- Camera title, Date & Time, Channel Title, Time Title, Location, Font Properties, Custom Title
- Bit Rate
- Camera title, Date & Time, Channel Title, Time Title, Location, Font Properties, Custom Title
- Bit Rate Control
- CBR/ VBR
- Protocol
- SFTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, PPPoE, NFS, UDP, UPnP, ICMP, SSL, DHCP, SMTP, RTSPS, InstaOn, ONVIF (Profile S, Profile G, Profile T), unicast, multicast
- Ethernet
- RJ-45 (10/100 Base-T)
- Image Rotation
- 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
- IMD (Intelligent motion detection)
- Support
- Audio Compression
- G.711a, G.711Mu, G.726, PCM, AAC
- Audio Input
- 1 Channel (RCA port)
- Audio Output
- 1 Channel (RCA port)
- Alarm IN
- 1 Channel in: 5 mA 3–5 VDC
- Alarm Out
- 1 Channel out: 300 mA 12 VDC
- Cyber Security
- AES 256-bit Encryption, Configuration encryption, trusted execution, Digest, security logs, WSSE, account lockout, syslog, video encryption, IP/MAC filtering, HTTPS, trusted upgrade, trusted boot
- SDK and API
- Support
- Alarm Event
- No SD card, SD card full, SD card error, Network disconnection, IP conflict, illegal access, Motion detection, Video tampering, Tripwire, Intrusion, Audio detection, Voltage detection, IMD (Intelligent motion detection), Security exception, External alarm
- Browser
- IE: IE11, Chrome, Firefox
- Storage
- SFTP, NAS, Mirco SD card (Max. 512GB)
- User/ Host
- 6 (Total bandwidth: 48 M)
- Certificates
- ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report
- Power Source
- 12 VDC/PoE (802.3af)
- Power Consumption
- Basic: 2.6 W (12 VDC), 3.4 W (PoE) Max. (H.265+ max. resolution + max. stream+ WDR + illuminator intensity + IVS): 7 W (12 VDC), 8.3 W (PoE)
- Weatherproof Standard
- IP67, IK10 (optional)
- Operating Temperature
- –40°C to +60°C
- Operating Humidity
- ≤95% (RH), non-condensing
- Storage Temperature
- –40°C to +60°C
- Storage Humidity
- ≤95% (RH), non-condensing
- Casing
- Metal
- Dimensions
- 238.6 mm × 90.7 mm × 90.7 mm
- Weight
- 700g
