1/2.8” 2MP PS CMOS Image Sensor (0.9071 centimeter)
1920(H) × 1080(V) @25/30 fps
Instastream, H.264+, H.265, H.264, H.264H, H.264B, MJPEG
Support Quad Stream
WDR(120dB), Two-Way Talk, Day/Night (ICR), 3D DNR, ROI, Defog, AWB, AGC, HLC, BLC
2.7mm-13.5mm Motorized Lens
IR Range of 60 Mtr.
Support Starlight Technology
Built in Mic, Digital watermarking ,Micro SD Card, IP67, IK10, PoE
- Image Sensor
- 1/2.8” 2MP PS CMOS Image Sensor (0.9071 centimeter)
- Minimum Illumination
- 0.006 Lux@F1.6(Color,30IRE), 0.006 Lux@F1.6(B/W,30IRE), 0 lux (IR on)
- Effective Pixels
- 1920 (H) × 1080 (V)
- Electronic Shutter
- Auto/Manual, 1/3s - 1/10000
- Angle Adjustment
- Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°
- RAM
- 512 MB
- ROM
- 128 MB
- White Balance
- Auto, Natural, Street lamp, Outdoor, Manual, Regional Custom
- Lens
- 2.7 mm–13.5 mm
- Gain Control (AGC)
- Auto
- Lens Type
- Motorized vari-focal
- Iris Control
- Fixed
- Max. Aperture
- F1.6
- Lens Mount
- M14
- Close Focus Distance
- 0.8 Mtr.
- DORI Distance
- Lens W: 44.1Mtr. (Detect), 17.7Mtr.(Observe), 8.8Mtr. (Recognize), 4.4Mtr(Identify) Lens T: 144.8Mtr(Detect), 57.9Mtr(Observe), 29.0Mtr(Recognize), 14.5Mtr(Identify)
- Back Light Compensation
- BLC/ HLC/ WDR(120dB)
- Angle of view
- Horizontal: 109°–30°, Vertical: 56° –17°, Diagonal: 131° –35°
- Streaming Capability
- Quad Stream
- Video Format
- PAL/NTSC
- Video Compression
- Instastream, H.265, H.264+, H.264, H.264H, H.264B, MJPEG (Only supported by the sub stream)
- Resolution
- 2MP (1920 × 1080), 1.3M (1280 × 960), 1MP (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240)
- Bit Rate Control
- CBR/VBR
- Noise Reduction
- 2D DNR
- Image Stabilization
- Electronic Image Stabilization (EIS)
- Motion Detection
- OFF/ON (8 areas, Rectangular)
- Audio Input
- 1 Channel (RCA port)
- Audio Output
- 1 Channel (RCA port)
- Audio Compression
- PCM, G.711a, G.711Mu, G.726, MPEG2-Layer2, G.722.1
- Alarm IN
- 1 channels in: 5mA 3V–5V DC
- OSD
- Camera title, Date & Time
- Protocol
- SFTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V1/ V2/ V3/, TCP/IP, PPPoE, NFS, UDP, ICMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T) , unicast, multicast
- IVS (Optional)
- Tripwire, Intrusion, Object Abandon/ Missing, IMD (Intelligent motion detection), Face Detection
- SDK and API
- Support
- Ethernet
- RJ-45 (10/100Base-T)
- Day/Night
- Auto(ICR)/Color/B/W
- Alarm Event
- Motion/tampering detection, audio detection, network disconnection detection, IP conflict detection, memory card state detection, memory space detection
- User/ Host
- 20 (Total bandwidth: 80 Mbps)
- Browser
- Microsoft Edge and Chrome
- Mirror Function
- Support
- Storage
- FTP, NAS, Mirco SD card (Max. 512GB)
- Frame Rate
- Main stream: 2MP/1.3MP/1MP/D1@(1-25/30fps) Sub stream 1: D1/VGA/CIF@(1-25/30fps) Sub stream 2: 2MP/1.3MP/1MP/D1@(1-25/30fps), Sub stream 3: D1/VGA/CIF@(1-25/30fps)
- IR
- 60 Mtr.
- IR Number
- 4 (IR LED)
- Image Rotation
- 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)
- Certificates
- MTBF Certificate from STQC, EMI/EMC, ISO9001, CE, FCC and RoHS, BIS, STQC approved compliance report
- Operating Temperature
- –30 °C to +60 °C (–22 °F to +140 °F)
- Storage Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity
- 10%–95% RH, non-condensing
- Power Source
- 12 VDC/PoE (802.3af)
- Power Consumption
- Basic: 1.6W (12 VDC), 3.3 W (PoE) Max. (H.265 + WDR + Intelligence on + IR on : 9.6W (12 VDC), 11.9W (PoE)
- Dimension
- 273.2 mm × 95.0 mm × 95.0 mm
- Weight
- 1.10 kg
