1/2.7" 8MP PS CMOS Image Sensor (0.9407 centimeters
Max. 8MP (3840 x 2160)@1ā25/30fps
Instastream, H.265, H.264, H.264H, H.264B, MJPEG
Support Quad Stream
WDR(120dB), Day/Night (ICR), 3D NR, Defog, BLC, HLC, AWB, AGC, Digital watermarking,
2.7mmā13.5mm Motorized Lens
IR Range of 60 Mtrs.
Support Starlight Technology
Support Built-in Mic
Micro SD Card, IP67, IK10, PoE
- Image Sensor
- 1/2.7" 8MP PS CMOS Image Sensor (0.9407 centimeters)
- Minimum Illumination
- 0.001 lux@F1.4 (Color, 30 IRE), 0.001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on)
- Effective Pixels
- 3840 (H) Ć 2160 (V)
- Shutter Speed
- Auto/Manual 1/3 sā1/10000
- Angle Adjustment
- Pan: 0Ā°ā360Ā°, Tilt: 0Ā°ā90Ā°, Rotation: 0Ā°ā360Ā°
- RAM
- 512 MB
- ROM
- 128 MB
- White Balance
- Auto, natural, street lamp, outdoor, manual, regional custom
- Lens
- 2.7mmā13.5mm
- Lens Type
- Motorized Lens
- Gain Control (AGC)
- Auto
- Iris Control
- Fixed
- Max. Aperture
- F1.4
- Lens Mount
- M14
- Close Focus Distance
- 0.8m
- DORI Distance
- Lens W: 44.1Mtr. (Detect), 17.7Mtr.(Observe), 8.8Mtr. (Recognize), 4.4Mtr(Identify) Lens T: 144.8Mtr(Detect), 57.9Mtr(Observe), 29.0Mtr(Recognize), 14.5Mtr(Identify)
- Back Light Compensation
- BLC/ HLC/ WDR(120dB)
- Angle of view
- Horizontal: 109Ā°ā30Ā°, Vertical: 56Ā° ā17Ā°, Diagonal: 131Ā° ā35Ā°
- Day/Night
- Auto(ICR)/Color/B/W
- Video Format
- PAL/NTSC
- Video Compression
- Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by the sub stream)
- Smart Compression
- AI H.265, AI H.264
- IR
- IR Range of 60 Mtr.
- IR Control
- Auto/Face Priority, Number Plate Priority/Manual
- Stream Capability
- Quad Stream
- Frame Rate
- Main stream: 8MP (3840 x 2160)@1ā25/30fps, 4MP (2688 x 1520)@1ā25/30fps, 2MP (1920 x 1080)@1ā25/30fps, 1.3MP (1280 x 960)@1ā25/30fps, 1MP (1280 Ć 720)@1ā25/30fps Sub stream 1: 2MP (1920 x 1080)@1ā15fps, 1.3MP (1280 x 960)@1ā15fps, 1MP (1280 x 720) @1ā15fps Sub stream 2: D1 (704 Ć 576/704 Ć 480)@1ā15, VGA ((640 Ć 480)@1ā15, CIF (352 Ć 288/352 Ć 240)@1ā15 fps Sub stream 3: D1 (704 Ć 576/704 Ć 480)@1ā15, VGA ((640 Ć 480)@1ā15, CIF (352 Ć 288/352 Ć 240)@1ā15 fps
- Resolution
- 8MP (3840 Ć 2160), 4MP (2688 Ć 1520), 3MP (2048 Ć 1536/ 2304 Ć 1296), 2MP (1920 Ć 1080), 1.3MP (1280 Ć 960), 1MP (1280 Ć 720), D1 (704 Ć 576/704 Ć 480), VGA (640 Ć 480), CIF (352 Ć 288/352 Ć 240)
- Smart IR
- Support
- Image Rotation
- 0Ā°/90Ā°/180Ā°/270Ā° (Support 90Ā°/270Ā° with 1080P resolution and lower)
- IR Number
- 4 IR LED
- Bit Rate Control
- CBR/VBR
- Bit Rate
- H.265: 3 kbpsā17664 kbps, H.264: 3 kbpsā17664 kbps
- Mirror Function
- Support
- Noise Reduction
- 2D NR
- Motion Detection
- OFF/ON (4 areas, rectangular)
- Privacy Mask
- 8 Areas
- Audio Input
- 1 Channel (RCA port)
- Audio Output
- 1 Channel (RCA port)
- Audio Compression
- PCM, G.711a, G.711Mu, G.726, AAC
- Alarm Out
- 1 channel out: 300mA 12V DC
- OSD
- Camera title, Date & Time
- Protocol
- FTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, Profile G, Profile T) , unicast, multicast
- Ethernet
- RJ-45 (10/100 Enhancement Base-T)
- Alarm Event
- No SD card, SD card full, SD card error, Network disconnection, IP conflict, Motion detection, Video tampering, Defocus detection
- Intelligent Scene Adaption (ISA)
- Support
- Cyber Security
- AES 256-bit Encryption, Configuration encryption, trusted execution, Digest, security logs, WSSE, account lockout, syslog, video encryption, IP/MAC filtering, HTTPS, trusted upgrade, trusted boot
- Storage
- SFTP, NAS, Micro SD card (support max. 512 GB)
- User/ Host
- 20 (Total bandwidth: 80 M)
- Browser
- Microsoft, Edge and Chrome
- Hardware Reset Point
- Support
- Certificates
- MTBF Certificate from STQC, ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report
- Power Source
- 12 VDC/PoE (802.3af)
- Power Consumption
- Basic: 1.6 W (12 VDC), 3.2 W (PoE) Max. (H.265+ WDR +IR on): 9.6 W (12 VDC), 10.8 W (PoE)
- Weatherproof Standard
- IP67
- Operating Temperature
- ā30 Ā°C to +60 Ā°C (ā22 Ā°F to +140 Ā°F)
- Operating Humidity
- ā¤95% RH, non-condensing
- Storage Temperature
- ā40 Ā°C to +60 Ā°C (ā40 Ā°F to +140 Ā°F)
- Storage Humidity
- 10%ā95% RH, non-condensing
- Casing
- Metal + Plastic
- Dimension
- 273.2mm Ć 95.0mm Ć 95.0mm
- Weight
- 1100g
