1/2.7” 6MP PS CMOS Image Sensor (0.9407 centimeters)
Max. 6MP (3288 × 1850)@20 fps
Instastream, H.265, H.264, H.264H, H.264B, MJPEG
Support Quad stream
WDR(120dB), Day/Night(ICR), 3D NR, ROI, AWB, AGC, BLC, HLC, Digital watermarking
IR Range of 50 Mtr., Warm Light Range of 30 Mtr.
3.6 mm fixed Lens (2.8 mm optional)
Support Starlight Technology
Micro SD Card, PoE, IP67, IK10
- Image Sensor
- 1/2.7
- Effective Pixels
- 3288 (H) × 1850 (V)
- Minimum Illumination
- 0.001 lux@F1.4 (Color, 30 IRE), 0.0001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on)
- Angle Adjustment
- Pan: 0°–355°, Tilt: 0°–65°, Rotation: 0°–355°
- Shutter Speed
- Auto/Manual 1/3 s–1/100,00
- White Balance
- Auto, Natural, Street lamp, Outdoor, Manual, Regional custom
- RAM
- 256 MB
- ROM
- 256 MB
- DORI Distance
- Lens 3.6 mm: 85.4 m (Detect), 34.2 m (Observe), 17.1 m (Recognize), 8.5 m (Identify); Lens 2.8 mm: 61.2 m (Detect), 24.5 m (Observe), 12.2 m (Recognize), 6.1 m (Identify)
- Gain Control(AGC)
- Auto/ Manual
- Lens Type
- Fixed-focal
- Max. Aperture
- F1.2
- Close Focus Distance
- 3.6 mm: 1.7 m, 2.8 mm: 1.0 m
- IR Number
- 3 IR LED, 4 Warm Light
- IR
- IR Range of 50 Mtr.
- Warm Light
- Warm Light Range of 30 Mtr.
- Lens
- 3.6 mm Lens (2.8 mm Optional)
- Lens Mount
- M12
- S/N Ratio
- >55dB
- Back Light Compensation
- BLC/ HLC/ WDR(120dB)
- Angle of view
- 3.6 mm: H: 91°, V: 46°, D: 110°; 2.8 mm: H: 112°, V: 61°, D: 132°
- Video Compression
- Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by sub stream)
- Frame Rate
- Main stream: 6MP (3288 × 1850)@20 fps, 4MP (2688 × 1520)@25/30 fps; Sub Stream 1: D1@25fps, Sub Stream 2: D1@25fps, Sub Stream 3:D1@1fps
- Resolution
- 6M (3288 × 1850), 5M (2880 × 1620), 4M (2688 × 1520), 3M (2048 × 1536/2304 × 1296), 2M (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240)
- Video Format
- PAL/NTSC
- ROI
- Support (8 areas)
- OSD
- Camera title, Date & Time
- Audio Compression
- G.711a, G.711Mu, PCM, G.726, A
- Protocol
- FTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, SSL, DHCP, SMTP, RTSPS, InstaOn, ONVIF (Profile S, Profile G, Profile T), unicast, multicast
- Ethernet
- RJ-45 (10/100 Base-T)
- Day/Night
- Auto(ICR)/Color/B/W
- Image Rotation
- 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
- IR Control
- Auto, Manual
- Bit Rate
- H.265: 3 kbps–8192 kbps, H.264: 3 kbps–8192 kbps
- Bit Rate Control
- CBR/VBR
- Storage
- FTP, NAS, Mirco SD card (Max. 512GB)
- Browser
- IE, Chrome, Firefox
- Audio Output
- 1 Channel (RCA port)
- Alarm IN
- 1 Channel in: 5 mA 3–5 VDC
- Alarm Out
- 1 Channel out: 300 mA 12 VDC
- Weatherproof Standard
- IP67, IK10
- User/Host
- 20 (Total bandwidth: 48 M)
- Certificates
- ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report
- Power Source
- 12 VDC,
- Power Consumption
- Basic: 2.2 W (12 VDC), 2.9 W (PoE); Max.: 6.8 W (12 VDC), 8.2 W (PoE) (H.265 + intelligence on+ WDR + illuminator intensity)
- Operating Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity
- ≤95% (RH), non-condensing
- Dimension
- 81.0 mm × 109.9 mm
