1/2.7” 8MP PS CMOS Image Sensor (0.9407 centimeters)
Max. 8MP (3840 × 2160)@1–20 fps
Instastream, H.265, H.264, H.264H, H.264B, MJPEG
Support Quad Stream
WDR(120dB), Day/Night(ICR), 2D NR, 3D NR, ROI, BLC, HLC, AWB, AGC, Digital watermarking
2.7 mm–13.5 mm Motorized Lens
IR Range of 50 Mtr.
Support Starlight Technology
Micro SD Card, IP67, IK10, PoE
- Image Sensor
- 1/2.7
- Effective Pixels
- 3840 (H) × 2160 (V)
- Minimum Illumination
- 0.001 lux@F1.4 (Color, 30 IRE), 0.0001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on)
- Angle Adjustment
- Pan: 0°–355°, Tilt: 0°–75°, Rotation: 0°–355°
- Shutter Speed
- Auto/Manual 1/3 s–1/100,000 s
- White Balance
- Auto, Natural, Street lamp, Outdoor, Manual, Regional custom
- ROM
- 128 MB
- RAM
- 128 MB
- Close Focus Distance
- 0.8 m
- Gain Control (AGC)
- Auto, Manual
- Lens Type
- Motorized Vari-focal
- Max. Aperture
- F1.2
- DORI Distance
- Lens W: 85.3 m (Detect), 34.1 m (Observe), 17.1 m (Recognize), 8.5 m (Identify); Lens T: 280.0 m (Detect), 112.0 m (Observe), 56.0 m (Recognize), 28.0 m (Identify)
- Lens
- 2.7 mm–13.5 mm
- Angle of view
- H: 113°–31°, V: 58°–18°, D: 138°–36°
- S/N Ratio
- >58 dB
- IR Number
- 2 IR LED
- IR
- IR Range of 50 Mtr.
- Day/Night
- Auto(ICR)/Color/B/W
- Back Light Compensation
- BLC/ HLC/ WDR(120dB)
- IR Control
- Auto, Manual
- Iris Control
- Fixed
- Smart search
- Work together with AI NVR to perform refine AI search, event extraction and merging to event videos
- Video Compression
- Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by the sub stream)
- Resolution
- 8MP (3840 × 2160), 6MP (3072 × 2048), 5MP (3072 × 1728), 4.6MP (2880 × 1620), 4MP (2688 × 1520), 3MP (2048 × 1536), (2304 × 1296), 2MP (1920 × 1080), 1.3MP (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240)
- Stream Capability
- Quad Stream
- Frame Rate
- Main stream: 8MP (3840 × 2160)@1–20 fps/ 4MP (2688 × 1520)@1–25/30 fps Sub Stream 1: D1@25fps Sub Stream 2: D1@25fps Sub Stream 3: D1@1fps
- Noise Reduction
- 2D NR, 3D NR
- Motion Detection
- OFF/ON (8 areas, rectangular)
- Video Format
- PAL/NTSC
- Bit Rate Control
- CBR/VBR
- Bit Rate
- H.265: 3 kbps–8192 kbps, H.264: 3 kbps–8192 kbps
- Protocol
- FTP, IPv6, IPv4, DNS,RTCP, NTP, RTP, HTTP, HTTPS, SNMP V3, TLS Version 1.2, TCP/IP, PPPoE, NFS, UDP, UPnP, ICMP, SSL, DHCP, SMTP, RTSPS, InstaOn, ONVIF (Profile S, Profile G, Profile T), unicast, multicast
- Ethernet
- RJ-45 (10/100 Base-T)
- Alarm Event
- No SD card, SD card full, SD card error, Network disconnection, IP conflict, illegal access, Motion detection, Video tampering, Tripwire, Intrusion, Audio detection, Voltage detection, Defocus detection, External alarm, IMD (Intelligent motion detection), Security exception
- Mirror Function
- Support
- Image Rotation
- 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
- User/ Host
- 6 (Total bandwidth: 48 M)
- Audio Compression
- G.711a, G.711Mu, G.726, PCM, AAC
- Audio Input
- 1 channel (RCA port)
- Audio Output
- 2 channel (RCA port)
- Alarm IN
- 1 Channel in: 5mA 3V–5 VDC
- Alarm Out
- 1 Channel out: 300mA 12 VDC
- Browser
- IE, Chrome, Firefox
- Storage
- FTP, NAS, Mirco SD card (Max. 512GB)
- Certificates
- ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report
- Power Source
- 12 VDC/PoE (802.3af)
- Power Consumption
- Basic: 2.7 W (12 VDC), 3.4 W (PoE) Max. (H.265+ max. resolution + max. stream+ WDR + IR intensity + IVS): 6.4 W (12 VDC), 7.3 W (PoE)
- Weatherproof Standard
- IP67, IK10
- Operating Temperature
- –30°C to +60°C
- Operating Humidity
- ≤95%
- Storage Temperature
- –30°C to +60°C
- Storage Humidity
- ≤95%
- Dimensions
- 93.4 mm × Φ122 mm
- Weight
- 510g
