English
1/2.8” 2MP PS CMOS Image Sensor (0.9071 Centimeter)
1920(H) × 1080(V) @25/30 fps
Instastream, H.265, H.264+, H.264, H.264H, H.264B, MJPEG
Support Quad Stream
WDR(120dB), Day/Night(ICR), 3D DNR, ROI, Defog, BLC, HLC, AWB, AGC
2.7mm ~13.5mm Motorized lens
IR Range of 40 Mtr.
Support Starlight Technology
Built-in Mic, Digital watermarking, Micro SD, IP67, IK10, PoE
- Image Sensor
- 1/2.8” 2MP PS CMOS Image Sensor (0.9071 Centimeter)
- Minimum Illumination
- 0.006 Lux@F1.6(Color,30IRE), 0.0006 Lux@F1.6(B/W,30IRE) 0 lux (IR on)
- Effective Pixels
- 1920 (H) × 1080 (V)
- Shutter Speed
- Auto/Manual 1/3 s–1/100,000 s
- Angle Adjustment
- Pan: 0°–355°, Tilt: 0°–65°, Rotation: 0°–355°
- RAM
- 512 MB
- ROM
- 128 MB
- White Balance
- Auto, natural, street lamp, outdoor, manual, regional custom
- Lens
- 2.7mm~13.5mm
- Gain Control(AGC)
- Auto
- Lens Type
- Motorized
- Max. Aperture
- F1.5
- Lens Mount
- M14
- Close Focus Distance
- 0.8 Mtr.
- DORI Distance
- W: 44.1 Mtr. (Detect), 17.7 Mtr. (Observe), 8.8 Mtr. (Recognize), 4.4 Mtr.(Identify) T: 144.8 Mtr. (Detect), 57.9Mtr. (Observe), 29.0Mtr. (Recognize), 14.5 Mtr. (Identify)
- Back Light Compensation
- BLC / HLC / WDR(120dB)
- Angle of view
- H: 109°–30°, V: 56°–17°, D: 131°–35°
- Stream Capability
- Quad Stream
- Video Format
- PAL/NTSC
- Video Compression
- Instastream, H.264+, H.265, H.264, H.264H, H.264B, MJPEG (Only supported by the sub stream)
- Resolution
- 2MP(1920 × 1080), 1.3MP(1280 × 960), 1MP(1280 × 720), D1(704 × 576/ 704 × 480), VGA(640 × 480), CIF(352 × 288/ 352 × 240)
- Bit Rate Control
- CBR/VBR
- Bit Rate
- H.264: 3 kbps–6144 kbps, H.265: 3 kbps–6144 kbps
- Noise Reduction
- 3D DNR
- Image Stabilization
- Electronic Image Stabilization (EIS)
- Motion Detection
- OFF/ON (4 Areas, Rectangular)
- Privacy Mask
- 4 Area
- ROI
- Support (4 Areas)
- Audio Output
- 1 Channel (RCA port)
- Audio Compression
- PCM, G.711a, G.711Mu, G.726, MPEG2-Layer2, G.722.1
- Audio
- Built-in Mic
- Alarm IN
- 1 channels in: 5mA 3V–5V DC
- Alarm Out
- 1 channel out: 300mA 12V DC
- OSD
- Camera title, Date & Time
- Protocol
- SFTP, IPv6, IPv4, DNS, RTCP, NTP, RTP, HTTP, HTTPS, SNMP V1/V2/V3, TCP/IP, PPPoE, UPnP, NFS, UDP, ICMP, SSL, DHCP, SMTP, RTSPS,ONVIF (Profile S,Profile G,Profile T), unicast, Multicast
- IVS (Optional)
- Tripwire, Intrusion, Object Abandon/ Missing, IMD (Intelligent motion detection), Face Detection
- SDK and API
- Support
- Ethernet
- RJ-45 (10/100Base-T)
- Day/Night
- Auto(ICR)/Color/B/W
- User/Host
- 20 (Total bandwidth: 80 Mbps)
- Browser
- Microsoft Edge and Chrome
- Mirror Function
- Support
- Storage
- SFTP, Micro SD card (support max. 512 GB), NAS
- Frame Rate
- Main stream: 2MP/1.3MP/1MP/D1 @(1-25/30fps) Sub stream 1: D1/VGA/CIF@(1-25/30fps) Sub stream 2: 2MP/1.3MP/1MP/D1@(1-25/30fps) Sub stream 3: D1/VGA/CIF@(1-25/30fps)
- IR Distance
- 40 Mtr. (IR)
- IR Number
- 3 (IR LED)
- Image Rotation
- 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)
- Certificates
- MTBF Certificate from STQC, EMI/EMC, ISO9001, CE, FCC and RoHS, BIS, STQC approved compliance report
- Weatherproof Standard
- IP67
- Operating Temperature
- –30 °C to +60 °C (–22 °F to +140 °F)
- Operating Humidity
- ≤95% RH, non-condensing
- Storage Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity
- 10%–95% RH, non-condensing
- Power Source
- 12 VDC/24 VAC/PoE (802.3af)
- Power Consumption
- Basic: 1.6 W (12 VDC), 1.9 W (24 VAC), 3.1 W (PoE) Max. (H.265 + WDR + Intelligence on + IR on: 7.9 W (12 VDC), 9.5 W (24 VAC), 9.9W (PoE)
- Dimension
- 159.1 mm × 118.1 mm
- Weight
- 0.91 kg
