1/2.8” 2MP PS CMOS Image Sensor (0.9071 centimeter)
1920(H) × 1080(V) @25/30 fps
H.265, H.264, H.264H, H.264B, MJPEG
Rotation mode, WDR(120dB), 3D DNR, HLC, BLC, AWB
2.8mm fixed lens (3.6mm optional)
IR Range of 30 Mtr.
Built-in Mic ,IP67, K10, Micro SD Card, PoE
- Image Sensor
- 1/2.8” 2MP PS CMOS Image Sensor (0.9071 centimeter)
- Minimum Illumination
- 0.006 Lux@F1.6(Color,30IRE), 0.0006 Lux@F1.6(B/W,30IRE) 0 lux (IR on)
- Effective Pixels
- 1920(H) × 1080(V)
- Shutter Speed
- Auto/Manual 1/3 s–1/100000 s
- Angle Adjustment
- Pan: -30°- 30°, Tilt: 0°- 80°, Rotation: 0°- 360°
- White Balance
- Auto/Manual
- Lens
- 2.8mm fixed lens (3.6mm optional)
- Gain Control (AGC)
- Auto/Manual
- Lens Type
- Fixed
- Iris Type
- Fixed
- Lens Mount
- M12
- Back Light Compensation
- BLC / HLC / WDR(120 dB)
- Angle of View
- 2.8mm: Horizontal: 107°, Vertical: 56.3°, Diagonal: 126.4°
- S/N Ratio
- > 54 dB
- Video Format
- PAL/NTSC
- OSD
- Camera title, Date & Time
- Video Compression
- Instastream, H.265, H.264+, H.264, H.264H, H.264B, MJPEG (only supported by the sub stream)
- Bit Rate Control
- CBR/VBR
- Bit Rate
- H.264: 3 kbps–6144 kbps, H.265: 3 kbps–6144 kbps
- Noise Reduction
- 3D DNR
- Privacy Mask
- 8 Areas
- Audio Compression
- PCM, G.711a, G.711Mu, G.726, MPEG2-Layer2, G.722.1
- Frame Rate
- Main stream: 2MP/1.3MP/1MP/D1@(1-25/30fps), Sub stream 1: D1/VGA/CIF@(1-25/30fps) Sub stream 2: 2MP/1.3MP/1MP/D1@(1-25/30fps), Sub stream 3: D1/VGA/CIF@(1-25/30fps)
- Protocol
- IPv4, IPv6, HTTPS, TCP/IP, HTTP, RTP, ARP, RTSP, SMTP, FTP, SFTP, DHCP, DNS, UPnP, NTP, Unicast, Multicast, NFS, PPPoE, SNMP, ICMP, ONVIF (Profile S, Profile G, Profile T)
- IVS (Optional)
- Tripwire, Intrusion, Object Abandon/ Missing, IMD (Intelligent motion detection), Face Detection.
- Day/Night
- Auto (ICR)
- Ethernet
- 1 (Built-in M12 port, and it supports the network data of 10 M/100 M)
- Alarm Event
- Motion/tampering detection, audio detection, network disconnection detection, IP conflict detection, memory card state detection, memory space detection
- Cyber Security
- AES 256-bit Encryption, Configuration encryption, trusted execution, Digest, security logs, WSSE, account lockout, syslog, video encryption, IP/MAC filtering, HTTPS, trusted upgrade, trusted boot.
- User/ Host
- 20 Users
- Browser
- Microsoft Edge and Chrome
- Operating Humidity
- ≤95% RH, Non condensing
- Operating Temperature
- –40°C to +70°C ,85°C (For 10 minutes)
- IR Distance
- IR Range of 30 Mtr.
- IR Number
- 2(IR Light)
- Certificates
- MTBF Certificate from STQC, EMI/EMC, ISO9001, CE, FCC and RoHS, BIS, STQC approved compliance report
- Storage
- SFTP, NAS, Micro SD card (support max. 512 GB)
- Power Source
- PoE (802.3af)
- Power Consumption
- < 4.5 W (PoE)
- Weatherproof Standard
- IP67, IK10
- Dimension
- 64.8mm × 111.0mm
- Casing
- Metal
- Weight
- 0.45kg
