1/2.8” 2MP PS CMOS Image sensor (0.9071 centimeters)
Max. 2MP (1920 × 1080)@1–25fps
Powerful 25x Optical and 16x Digital zoom
WDR(120dB), Day/Night(ICR), 2D NR/ 3D NR, Defog, AWB, AGC, BLC, HLC
Up to 300 Presets, 5 Scan, 8 Tour, 5 Pattern
Support Starlight Technology
IR Range of 100 Mtr., IP66
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite, EVMS Pro
- Image Sensor
- 1/2.8” 2MP PS CMOS Image sensor (0.9071 centimeters)
- Effective Pixels
- 1920 (H) × 1080 (V)
- Electronic Shutter
- 1/1 s–1/30,000 s
- Max. Aperture
- F1.6–F3.5
- RAM
- 512 MB
- ROM
- 256 MB
- Minimum Illumination
- 0.005 lux@F1.6 (Color, 30 IRE), 0.0005 lux@F1.6 (B/W, 30 IRE), 0 lux (IR light)
- White Balance
- Auto, Indoor, Outdoor, Tracking, Manual, Sodium lamp, Natural light, Street lamp
- S/N Ratio
- ≥55 dB
- Focus Control
- Auto, Semi-auto, Manual
- Lens
- 4.8 mm–120 mm
- Close Focus Distance
- 0.1 m–1.5m
- Angle of View
- H: 60.6°–3.2°; V: 34.1°–1.8°; D: 69.4°–3.7°
- Iris Control
- Auto, Manual
- DORI Distance
- 1655.2 mm (Detect), 653.8 mm (Observe), 331.0 mm (Recognize), 165.5 mm (Identify)
- Back Light Compensation
- BLC/ HLC/ WDR(120dB)
- IR Control
- Zoom Prio, Manual, Auto
- IR Number
- 3 IR
- Day/Night
- Auto (ICR)/Color/B/W
- IR
- IR Range of 100 Mtr.
- Video Format
- PAL
- Bit Rate
- H265: 86 kbps–5632 kbps, H264: 256 kbps–8192 kbps
- Overlay
- Channel Title, Time Title, OSD Info (PTZ Coordinate, Zoom, North, Pattern, Temperature, Preset, Location, Input Text, Text Alignment), Font Properties, Custom Title, Exception Overlay
- Gain Control (AGC)
- Auto, Manual
- Resolution
- 2MP (1920 × 1080), 720p (1280 × 720), D1 (704 × 576),CIF (352 x 288)
- Pan/Tilt Angle
- Pan: 0° to 360° endless, Tilt: –15° to +90°, auto flip 180°
- Optical Zoom
- 25×
- Digital Zoom
- 16x
- Image Rotation
- 180°
- Defog
- Electronic
- Special Features
- Up to 300 Presets, 5 Pattern, 8 (up to 32 presets per tour) Tour, 5 Scan
- Frame Rate
- Main stream: 2MP (1920 × 1080)@1–25fps, 720p, D1@1–25fps Sub stream 1: D1/CIF@1–25fps, Sub stream 2: 2MP (1920 × 1080)@1–25fps, 720p, D1@1–25fps Sub stream 3: D1/CIF@1–25fps, Sub stream 4: D1/CIF@1–25fps
- Bit Rate Control
- CBR/VBR
- IMD
- Support
- Noise Reduction
- 2D NR/3D NR
- Stream Capability
- Penta stream
- Idle Motion
- Pattern, Preset, Scan, Tour
- Protocol
- IPv4, IPv6, HTTP, HTTPS, TCP, UDP, RTP, RTSP, RTCP, RTMP, SMTP V3, SFTP, DHCP, DNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NAS, PPPoE, SNMP, Auto Connect, TLS v1.2 and v1.3, ONVIF (Profile S, Profile G, Profile T), InstaOn
- Device Search Tool
- IP finder
- OTA (Over-The-Air)
- Support
- SDK and API
- Support
- Power-off Memory
- Support
- Manual Speed
- Pan: 0.1°–80°/s, Tilt: 0.1°–80/s
- Preset Speed
- Pan: 80°/s, Tilt: 80°/s
- Event Alarm
- Motion Detection, Defocus Detection, Disk Full, Disk Error, Video Tampering, External Alarm, Security Warning, Audio Detection, AI Event
- Alarm Linkage
- Capture, Recording, Send email, Preset, Tour, Pattern, Alarm digital output
- Privacy Mask
- Support
- IVS (Perimeter Protection)
- Crossing virtual fence, Tripwire, Intrusion, Abandoned Object, Fast Moving, Parking Detection, Crowd Gathering, Missing Object, Loitering Detection, Face Detection, IMD
- Cyber Security
- AES 256-bit Encryption, Configuration encryption, Trusted execution, Digest, Security logs, WSSE, Account lockout, Syslog, Video encryption, 802.1x, Allow list/Block list, HTTPS, Trusted upgrade, Trusted boot, Firmware encryption
- Audio In
- 1 Channel
- Audio Out
- 1 Channel
- Alarm IN
- 2 (on-off value input: 0–5 VDC)
- Alarm Out
- 1 Channel
- Reset Button
- Support
- Weatherproof Standard
- IP66, TVS 6000V lightning proof, Surge protection, Voltage transient protection
- Storage
- SFTP, NAS, Mirco SD card (Max. 512GB)
- Certificates
- ISO 9001: 2015, ISO 20000-1 : 2018, ISO 14001 : 2015, ISO 45001 : 2018, ISO 50001:2018, CE, FCC and RoHS, BIS, STQC approved compliance report
- Power Source
- 12 VDC, 3 A ± 10%
- Power Consumption
- Basic: 6.5 W Max.: 17.25 W
- Operating Temperature
- –40 °C to +65 °C
- Operating Humidity
- ≤ 95% (RH)
- Dimension
- 270.4 mm × 160.0 mm
- Weight
- 2400g
