1/2.8” 2MP PS CMOS Image sensor (0.9071 centimeters)
Max. 2MP (1920 × 1080)@1–25fps
Powerful 32x Optical and 16x Digital zoom
WDR(120dB), 2D NR/ 3D NR, Day/Night(ICR), ROI, Defog, AWB, BLC, HLC
Support Penta stream
Up to 300 Presets, 5 Scan, 8 Tour, 5 Pattern
Support Starlight Technology
IR Range of 180 Mtr.
Support PoE+, IP67, IK10
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite, EVMS Pro
- Image Sensor
- 1/2.8” 2MP PS CMOS Image sensor (0.9071 centimeters)
- Effective Pixels
- 1920 (H) × 1080 (V)
- Max Aperture
- F1.6–F4.0
- S/N Ratio
- ≥55 dB
- RAM
- 512 MB
- ROM
- 256 MB
- Minimum IR
- Color: 0.005 lux@F1.6, B/W: 0.0005 lux@F1.6, 0 lux (IR light on)
- Focal Length
- 4.5 mm–144 mm
- Focus Control
- Auto, semi-auto, manual
- White Balance
- Auto, Indoor, Outdoor, ATW, Manual, Sodium lamp, Natural light, Street lamp
- Angle of View
- H: 58.4°–3.0°, V: 33.4°–1.7°, D: 66.4°–3.4°
- Close Focus Distance
- 0.1 m–1.5 m
- Iris Control
- Auto, Manual
- Resolution
- 2MP (1920 × 1080), 720p (1280 × 720), D1 (704 × 576), CIF (352 × 288)
- DORI Distance
- 1986 m (Detect), 785 m (Observe), 398 m (Recognize), 198 m (Identify)
- Electronic Shutter
- 1/1 s–1/30,000 s
- Back Light Compensation
- BLC/ HLC/ WDR(120dB)
- Optical Zoom
- 32×
- Digital Zoom
- 16x
- Bit Rate
- H265: 188 kbps–6400 kbps, H264: 216 kbps–8192 kbps
- Image Rotation
- 180°
- Pan/ Tilt Range
- Pan: 0° to 360°, Endless, Tilt: –15° to +90°, Auto flip 180°
- Power-off Memory
- Support
- IMD
- Support
- Day/Night
- Auto (ICR)/Color/B/W
- Video Format
- PAL
- OSD
- Channel Title, Time Title, OSD Info (PTZ Coordinate Zoom North, Pattern Temperature, Preset, Location, Input Text, Text Alignment), Font Properties, Custom Title, Exception Overlay
- Manual Speed
- Pan: 0.1°/s–300°/s, Tilt: 0.1°/s–200°/s
- Noise Reduction
- 2D NR/ 3D NR
- Preset Speed
- Pan: 400°/s, Tilt: 300°/s
- Image Stabilization
- Electronic Image Stabilization (EIS)
- Special Features
- Up to 300 Presets, 5 Pattern, 8 (up to 32 presets per tour) Tour, 5 Scan
- Privacy Mask
- Up to 24 areas can be set, with up to 8 areas in the same view
- Defog
- Electronic
- Idle Motion
- Pattern, Preset, Scan, Tour
- Stream Capability
- Penta stream
- IR Number
- 4 IR
- IR
- 180 Mtr.
- IR Control
- Zoom Prio, Manual, Smart IR, Off
- Gain Control (AGC)
- Auto, Manual
- Video Compression
- Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Sub Stream 1)
- Bit Rate Control
- CBR/VBR
- Frame Rate
- Main stream: 2MP (1920 × 1080)@1–25fps, 720p (1280 x 720)@1–25fps, D1 (704 x 576)@1 25fps Sub stream 1: D1 (704 x 576)@1–25fps, CIF (352 x 288)@1–25fps Sub stream 2: 2MP (1920 × 1080)@1–25fps, 720p (1280 x 720)@1–25fps, D1 (704 x 576)@1 25fps Sub stream 3: D1 (704 x 576)@1–25fps Sub stream 4: D1 (704 x 576)@1–25fps
- Motion Detection
- Support
- Audio Compression
- PCM, G.711A, G.711MU, G.726, MPEG2- Layer2, G.722.1, AAC
- Auto Tracking
- Support
- ROI
- Support
- Ethernet
- 1 × RJ-45 (10/100 Base-T)
- Audio Input
- 1 Channel
- Audio Output
- 1 Channel
- IVS (Perimeter Protection)
- Crossing Virtual Fence, Tripwire, Intrusion, Abandoned Object, Fast Moving, Parking Detection, Crowd Gathering, Missing Object, Loitering Detection, IMD
- Device Search Tool
- IP finder
- OTA (Over-The-Air)
- Support
- SDK and API
- Support
- Protocols
- IPv4, IPv6, HTTP, HTTPS, TCP, UDP, RTP, RTSP, RTCP, RTMP, SMTP V3, SFTP, DHCP, DNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NAS, PPPoE, SNMP, Auto Connect, TLS v1.2 and v1.3, ONVIF (Profile S, Profile G, Profile T), InstaOn
- Alarm I/O
- 2 IN/ 1 OUT
- Alarm Linkage
- Capture, Recording, Send email, Preset, Tour, Pattern, Alarm digital output
- Event Alarm
- Motion Detection, Defocus Detection, Disk Full, Disk Error, Video Tampering, External Alarm, Security Warning, Audio Detection, AI Event
- Cyber Security
- AES 256-bit Encryption, Configuration encryption, Trusted execution, Digest, Security logs, WSSE, Account lockout, Syslog, Video encryption, 802.1x, Allow list/Block list, HTTPS, Trusted upgrade, Trusted boot, Firmware encryption
- Reset Button
- Support
- Face Detection
- Face detection, Face Enhancement, Face Cutout(Face/ One Inch Photo), Snapshot Mode (Real- Time/ Quality Priority), Optimal face snapshot upload, Quality Threshold
- Browser
- IE, Chrome, Firefox
- Storage
- SFTP, NAS, Mirco SD card (Max. 512GB)
- Certificates
- ISO 9001: 2015, ISO 20000-1 : 2018, ISO 14001 : 2015, ISO 45001 : 2018, ISO 50001:2018, CE, FCC and RoHS, BIS, STQC approved compliance report
- Power Source
- 24 VDC, 2.5 A ± 25% PoE+ (802.3at)
- Power Consumption
- Basic: 8 W Max: 18.5W (illuminator on)
- User/ Host
- 20 (total bandwidth: 64 Mbps)
- Weatherproof Standard
- IP67, IK10, TVS 6000V lightning proof, surge protection, voltage transient protection
- Operating Temperature
- –40°C to +70°C
- Operating Humidity
- ≤ 95% (RH)
- Dimension
- 332 mm × 190 mm
- Weight
- 4600g
