English
1/2.8” 4MP PS CMOS Image sensor (0.9071 centimeters)
Max. 4MP (2688 x 1520/ 2560 x 1440)@1–25/30fps
Instastream, H.265, H.264, H.264H, H.264B, MJPEG
Support Triple Stream
Powerful 45x Optical and 16x Digital zoom
WDR(120dB), 2D NR/ 3D NR, Day/Night(ICR), ROI, Defog, AWB, BLC, HLC
Up to 300 Presets, 5 Scan, 8 Tour, 5 Pattern
Support Starlight Technology
IR Range of 300 Mtr.
Support PoE+, IP67, IK10
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite, EVMS Pro
- Image Sensor
- 1/2.8” 4MP PS CMOS Image sensor (0.9071 centimeters)
- Effective Pixels
- 2688 (H) x 1520 (V)
- Minimum Illumination
- 0.005 lux@F1.6 (Color, 30 IRE), 0.0005 lux@F1.6 (B/W, 30 IRE), 0 lux@F1.6 (IR on)
- Electronic Shutter
- 1 s–1/30000 s
- RAM
- 512 MB
- ROM
- 256 MB
- White Balance
- Auto, Indoor, Outdoor, ATW, Manual, Sodium lamp, Natural light, Street lamp
- Lens
- 3.95 mm–177.75 mm
- Max. Aperture
- F1.6–F4.95
- Angle of View
- H: 65.7°–1.9°, V: 39.4°–1.1°, D: 73.1°–2.1°
- Close Focus Distance
- 0.1 m–1 m
- Iris Control
- Auto, Manual
- DORI Distance
- 2,451.7 m (Detect), 972.9 m (Observe), 490.3 m (Recognize), 245.2 m (Identify)
- Focus Control
- Auto, Semi-auto, Manual
- Back Light Compensation
- BLC/ HLC/ WDR(120dB)
- Overlay
- Channel Title, Time Title, OSD Info (PTZ Coordinate, Zoom, North, Pattern, Temperature, Preset, Location, Input Text, Text Alignment), Font Properties, Custom Title, Exception Overlay
- Video Format
- PAL
- S/N Ratio
- ≥55 dB
- Optical Zoom
- 45×
- Digital zoom
- 16x
- Image Rotation
- 180°
- Pan/Tilt Angle
- Pan: 0° to 360°, endless, Tilt: –20° to +90°, Auto flip 180°
- Power-off Memory
- Support
- Manual Speed
- Pan: 0.1°/s–260°/s, Tilt: 0.1°/s–120°/s
- Preset Speed
- Pan: 0.1°/s–300°/s, Tilt: 0.1°/s–200°/s
- Image Stabilization
- Electronic Image Stabilization (EIS)
- Privacy Masking
- Up to 24 areas can be set, with up to 8 areas in the same view
- Special Features
- Up to 300 Presets, 5 Pattern, 8 (up to 32 presets per tour) Tour, 5 Scan
- Idle Motion
- Pattern, Preset, Scan, Tour
- IR
- IR Range of 300 Mtr.
- IR Number
- 6 IR
- IR Control
- Zoom Prio, Manual, Smart IR, Off
- Day/Night
- Auto (ICR)/Color/B/W
- Gain Control
- Auto, Manual
- Video Compression
- Instastream, H.265, H.264, H.264H, H.264B, MJPEG (Sub Stream1)
- Resolution
- 4MP (2688 x 1520), 4MP (2560 x 1440), 3MP (2304 x 1296), 1080p (1920 ×1080), 720p (1280 × 720), D1, VGA, CIF
- Stream Capability
- Triple Stream
- Frame Rate
- Main stream: 4MP (2688 x 1520/ 2560 x 1440)@1–25fps, 3MP (2304 x 1296)@1–25fps, 2MP (1920 × 1080)@1–25fps, 720p, Sub stream 1: D1/VGA/CIF@1–25 fps Sub stream 2: 720P@1–25fps
- Defog
- Electronic
- Bit Rate
- H265: 86 kbps–8192 kbps, H264: 216 kbps–8192 kbps
- Bit Rate Control
- CBR/VBR
- Motion detection
- Support
- RS-485
- 1 Channel
- ROI
- Support
- Audio In
- 1 Channel
- Audio Out
- 1 Channel
- Audio Compression
- PCM, G.711A, G.711MU, G.726, MPEG2-Layer2, G.722.1
- Auto Tracking
- Support
- Alarm IN
- 7 Channels (on-off value input: 0–5 VDC)
- Alarm Out
- 2 Channels
- Event Alarm
- Motion Detection, Defocus Detection, Disk Full, Disk Error, Video Tampering, External Alarm, Security Warning, Audio Detection, AI Event
- Noise Reduction
- 2D NR/ 3D NR
- Cyber Security
- AES 256-bit Encryption, Configuration encryption, Trusted execution, Digest, Security logs, WSSE, Account lockout, Syslog, Video encryption, 802.1x, Allow list/Block list, HTTPS, Trusted upgrade, Trusted boot, Firmware encryption
- Protocol
- IPv4, IPv6, HTTP, HTTPS, TCP, UDP, RTP, RTSP, RTCP, RTMP, SMTP V3, SFTP, DHCP, DNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NAS, PPPoE, SNMP, Auto Connect, TLS v1.2 and v1.3, ONVIF (Profile S, Profile G, Profile T), InstaOn
- Reset Button
- Support
- Device Search Tool
- IP finder
- OTA (Over-The-Air)
- Support
- SDK and API
- Support
- IVS (Perimeter Protection)
- Crossing virtual fence, Tripwire, Intrusion, Abandoned Object, Fast Moving, Parking Detection, Crowd Gathering, Missing Object, Loitering Detection, IMD
- Face Detection
- Face detection, Face Enhancement, Face Cutout (Face/ One Inch Photo), Snapshot Mode (Real-Time/ Quality Priority), Optimal face snapshot upload, Quality Th
- User/Host
- 20 (Total bandwidth: 64 M)
- Ethernet
- RJ-45 (10/100 Base-T)
- Alarm Linkage
- Capture, Recording, Send email, Preset, Tour, Pattern, Alarm digital output
- Storage
- SFTP, NAS, Mirco SD card (Max. 512GB)
- Certificates
- ISO 9001: 2015, ISO 20000-1 : 2018, CE, FCC and RoHS, BIS, STQC approved compliance report
- Power Source
- 24 VDC, 2.5 A ± 25% PoE+ (802.3at)
- Power Consumption
- 24 VDC, 2.5 A ± 25%: Basic: 13 W, Max: 25 W (IR + PTZ) PoE+ (802.3at): Basic: 13 W, Max: 25 W (IR + PTZ)
- Weatherproof Standard
- IP67, IK10, TVS 6000 V lightning proof, Surge protection, Voltage transient protection
- Browser
- Microsoft Edge, Chrome, Firefox
- Operating Temperature
- –40 °C to +70 °C (–40 °F to +158 °F)
- Operating Humidity
- ≤ 95% (RH)
- Dimension
- 337.4 mm × 209 mm
- Weight
- 5900g
