Support 4 channel IP camera input
Max 80Mbps Network Bandwidth
Instastream/H.265/Smart H.264+/H.264 codec decoding
Up to 8MP resolution preview and playback
Support 4 PoE Ports
Support 1 SATA HDDs up to 8TB, 2 USB Ports (USB2.0)
VGA/HDMI simultaneous video output, maximum resolution of HDMI is 1080P
Support Multi-brand network cameras
ONVIF Version conformance
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro
- Processor
- Industrial-grade embedded processor
- IP Camera Input
- 4 channel
- Operating System
- Embedded LINUX
- RCA Input/ RCA Output
- 1 Channel Input/ 1 Channel output
- User Interface
- Web/operating in local GUI
- Video Output
- 1 VGA/1 HDMI simultaneous video output, maximum resolution 1080P
- Video Compression
- Instastream/H.265/Smart H.264+/H.264
- Audio Compression
- PCM/G711A/G711U/G726/AAC
- Decoding Capability
- 1–ch@8MP(30FPS) or 1–ch@5MP(30FPS) or 2–ch@4MP(30FPS) or 2–ch@3MP(30FPS) or 4–ch@1080P(30FPS)
- Resolution
- 5MP/4MP/3MP/1080P/720P/D1/CIF
- Storage
- Local HDD & Network
- Network Bandwidth
- 80 Mbps for access, 80 Mbps for storage and 60 Mbps for forwarding.
- Video Display Split
- 1/4
- Multi-channel Playback
- Up to 4 Channel
- Playback Function
- Play, pause, stop, fast forward, fast backward, rewind, play by frame, Full screen, backup (cut/file), partially enlarge, audio on/of
- Alarm Linkage
- Video recording, snapshot, log, preset, tour
- Hard Disk
- 1 SATA 2.0, up to 8TB Each
- Backup Mode
- USB Device
- Interface Ports
- 2 USB Ports (1 Rear USB 2.0 , 1 Front USB 2.0 )
- Smart Phone
- iPhone, iPad, Android Phone
- Ethernet
- 1 RJ-45 Port (10/100Mbps)
- PoE Ports
- 4 RJ–45 ports with PoE power supply (10/1000 Mbps)
- Protocols
- HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, InstaOn, ONVIF (profile T/profile S/profile G), RTSP, CGI, SDK
- Power Supply
- DC48V/53V, 1.25A
- Power Consumption
- Total output of NVR is <10W (Without HDD), Total output power of PoE is 36W, the maximum output power of a single port is 25.5W
- Operating Temperature
- -10°C to 45°C (+34°F to +113°F)
- Storage Temperature
- 0°C to 40°C (+32°F to +104°F)
- Operating Humidity
- 10%~93%
- Storage Humidity
- 30%~85%
- Operating Altitude
- 3000m
- Dimension
- 260 mm×225 mm×47.6 mm (W × L × H)
- Weight
- 0.84kg (without HDD)
