16 Channel IP video access
Instastream/H.265/Smart H.264 /H.264 encoding
Support 1 SATA HDDs up to 16TB each, 2 USB Ports
1 HDMI/ 1 VGA simultaneous video output
Support Multi-brand network cameras
- Max. decoding capability
- 6 × 1080p@30 fps. Supports adaptive decoding
- AI by camera
- perimeter protection,and SMD Plus
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro
- Processor
- Industrial-grade embedded processor
- Operating System
- Embedded LINUX
- IP Camera Input
- 16 channel
- Two-way Talk
- 1 Ch. audio in/1 Ch. out, RCA
- User Interface
- Web, Local, GUI
- Video Output
- 1 × VGA, 1 × HDMI (simultaneous)
- Resolution
- 12MP; 8MP; 5MP; 4MP; 3MP; 2MP; 720p; D1
- AI by Camera
- Perimeter protection; SMD Plus
- Video Compression
- H.265/Smart H.264+/H264
- Encode Strategy
- Instastream
- AI by Device
- n/a
- Video Display Split
- 1/4/8/9/16
- Audio Compression
- PCM; G.711A; G.711U; G.726
- Decoding Capability
- 1-channel 12MP@30 fps
- 1-channel 8MP@30 fps
- 2-channel 5MP@30 fps
- 3-channel 4MP@30 fps
- 6-channel 1080p@30 fps
- Audio Output
- 1 channel
- Audio Input
- 1 channel
- Camera Blank
- Supports
- Motion Detection
- MD Zones: 396 (22 × 18)
- Video Loss
- Supports
- Alarm Linkage
- Recording; snapshot; buzzer; log; preset; email; tour
- AI Search
- n/a
- General Alarm
- Motion detection; privacy masking; video loss; PIR alarm
- Smart Phone
- iPhone, iPad, Android Phone
- Abnormal Alarm
- Camera offline
- storage error
- disk full
- IP conflict
- MAC conflict
- login lock
- cyber security exceptio
- Hard Disk
- 1 SATA III ports, up to 16 TB for a single HDD. The maximum HDD capacity varies with environment temperatu
- Recording Mode
- Manual record; alarm record; motion detection record; schedule record
- Backup Mode
- USB device
- Playback
- 1. Play
- pause
- stop
- fast forward
- fast backward
- rewind
- play by frame 2. Full screen
- backup (video clip/file)
- partially zom in
- audio on/of
- Record Interval
- n/a
- Ethernet
- 1 × RJ-45, 10/100Mbps self-adaptive Ethernet port
- Interface Ports
- 2 USB Ports (1 × front USB2.0; 1 × back USB2.0)
- Protocols
- HTTP
- HTTPS
- TCP/IP
- IPv4
- RTSP
- UDP
- NTP
- DHCP
- DNS
- SMTP
- UPnP
- IP Filter
- DDNS
- Alarm Server
- InstaOn Cloud
- ONVIF (profile T/S/G)
- CGI
- SDK
- Power Supply
- 12V DC, 1.5A
- Power Consumption
- Total output of NVR is ≤ 10 W (without HDD)
- Working Temp
- -10°C to 55°C (+14°F to +113°F)
- Storage Temperature
- n/a
- Dimension
- 260 mm × 232.7 mm × 47.6 mm (W × L × H)
- Operating Altitude
- 3000 m
- Weight
- 0.81 kg
