Up to 8 Channel IP camera input
Instastream, H.265, H.264+, H.264, MJPEG
Support Digital Watermarking
2 SATA ports, only support SSD , up to 8 TB, 2 USB Ports (USB3.0 port), 1 HDMI, 1VGA
- Total Bandwidth
- - 192Mbps (Incoming/ Outgoing)
- AI by Recorder
- Face recognition
- AI by Camera
- Face detection, SMD
- Processor
- Industrial-grade processor
- IP Camera Input
- Video: 8 Channels, Audio: 2 Channels (IP MIC)
- Operating System
- Embedded Linux
- User Interface
- Web, Local GUI
- AI by Camera
- Face detection, IMD
- AI by NVR
- Face recognition
- AI By RDAS
- Eye drowsiness detection, Yawning detection, Distracted detection, Phone call detection, Smoking detection, No driver detection, Head phone detection, Camera covered, Lower Head
- Video Output
- 1 HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720, 800 x 600 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720, 800 x 600
- Wireless Frequency
- 2.4 GHz/ 5 GHz
- Abnormality Alarm
- Camera disconnection, Storage error, Disk full, IP conflict, MAC conflict, Login locked, and cybersecurity exception
- Wireless standard
- 802.11 b/g/n
- Bands
- 3G: B1/B2/B4/B5(B6,B19)/B8 4G: B1/B2(B25)/B3/B4(B66)/B26(B5,B18,B19)/B7/B8/B12(B17)/B13/B14/B20/B28/B29(SDL)/ B30/ B32(SDL)/B34/B38/B39/B40/B41/B42/B43/B46(SDL)/B48/B71 5G: N1/N2/N3/N5/N7/N8/*N12/*N13/*N14/*N18/N20/N25/*N26/N28/*N29(SDL)/N30/ N38/N40/N41/N48/N66/N71/N75(SDL)/*N76(SDL)/N77/N78/N79
- Face Recognition AI by NVR
- 6 Channel FD (by camera) + FR (by recorder)
- Face Detection
- 6 Channels
- IMD By Camera
- Human and vehicle detection on all channels, supporting up to 16 targets per second
- Network Bandwidth
- Total Bandwidth:- 192Mbps (Incoming/ Outgoing)
- Video Display Split
- 1/2/4/8
- Record Mode
- General, Motion detection, Intelligent, Alarm
- Audio Compression
- G.711a, G.711Mu, PCM, G726
- Timing interval 1-30 minutes configurable
- Unique Face detection with Metadata along with configurable timing interval
- GPS
- Built-in high accurate GPS module
- Resolution
- 16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 2MP, 720p, 960p, D1, CIF
- Decoding Capability
- 1 Channel 16MP@30 fps, 2 Channel 12MP@30 fps, 4 Channel 8MP@30 fps, 4 Channel 6MP@30 fps, 6 Channel 5MP@30 fps, 8 Channel 4MP@45 fps, 8 Channel 2MP@30 fps
- Video Compression
- Instastream, H.265, H.264+, H.264, MJPEG
- Audio Input
- 2 Channel, M12 connectors
- Audio Output
- 1 Channel, RCA Port
- Alarm Input
- 2 Channels, M12 connectors
- Hard Disk
- 2 SATA ports, only support SSD, up to 8 TB.
- General Alarm
- Motion detection, Privacy masking, Video loss, Scene changing, PIR alarm, IPC external alarm
- Intelligent Alarm
- Face detection, Face recognition, IMD+, Eye drowsiness detection, Yawning detection, Dis tracted detection, Phone call detection, Smoking detection, No driver detection, Head phone detection, Camera covered
- Browser
- Chrome, IE9 and later, Firefox
- Playback Mode
- Instant playback, General playback, Event playback, Tag playback, Smart playback
- Playback
- 1. Search conditions: Search for image by channels, type (human, vehicle), and start/end time 2. Functions: Supports recording playback (10 seconds before/after the event) and exporting search results of videos
- Interface Ports
- 2 USB Ports (USB3.0 port), 1 RS232 (M12 connectors), 1 RS485 (M12 connectors)
- Ethernet
- 2 (10/100/1000 Mbps Ethernet port, M12 connectors)
- Protocols
- HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, InstaOn, Auto Correction, ONVIF 24.12(Profile T, Profile S, Profile G,Profile M), CGI, SDK
- PoE
- 8 ports, 10/100 Mbps, IEEE 802.3 af/at, M12 connectors
- Recording Resolution
- 4MP @45fps
- Camera Search
- Interface to search IP address of connected Camera
- Mobile Communication
- Auto fallback from 5G to 4G
- Antennas
- Antenna for Wi-Fi, GPS and 5G/4G
- Pre-recording
- Support
- Post-recording
- Support
- Tampering Alarm
- Support (Video Tampering)
- Video Format
- CPV, MP4, AVI
- Logs
- User/Operator, Events and Alarms
- Certificates
- ISO 9001: 2015, ISO 20000-1 : 2018, ISO 14001 : 2015, ISO 45001 : 2018, ISO 50001:2018, CE, FCC and RoHS, BIS, EMI/EMC, Environment, Mould growth
- Power Supply
- 72–110 VDC
- Power Consumption
- 150W
- Operating Temperature
- –25°C to +85°C (-13°F to +158°F)
- Operating Humidity
- 10%–95% (RH), non-condensing
- Backup Method
- SSD, USB device and network
- Operating Altitude
- 3000 m
- Dimensions
- 380 mm x 262 mm x 72 mm
- Weight
- 5750g
