Support up to 4Ch. IP Camera Input
Instastream, H.265, H.264+, H.264, MJPEG
Support 4G
Max. 80/80/60 Mbps Incoming/ Recording/ Outgoing bandwidth
Support one-click arming and disarming
- AI by NVR
- Support 4 Channel IMD
- AI by Camera
- Support perimeter protection and IMD
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite
- Processor
- Industrial-grade processor
- IP Camera Input
- 4 Channels
- Operating System
- Embedded Linux
- User Interface
- Web, Local GUI
- AI by Camera
- Perimeter protection, IMD
- AI by NVR
- IMD
- Perimeter Performance of AI by Camera
- 4 Channels
- Video Output
- 1 HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Abnormality Alarm
- Error (No disk, Disk error, Low space, Low quota space, Network disconnection, IP conflict, MAC conflict), Video loss, Video tampering, Camera offline
- IMD+ by NVR
- 4 Channels: Secondary filtering for human and motor vehicle, Reducing false alarms caused by leaves, Rain and lighting condition change
- IMD+ by Camera
- 8 Channels
- Resolution
- 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 2MP, 720p, 960p, D1, CIF, QCIF
- Network Bandwidth
- 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing
- Decoding Capability
- AI disabled: 1 Channel 12MP@30 fps, 1 Channel 8MP@30 fps, 2 Channel 6MP@30 fps, 2 Channel 5MP@30 fps, 3 Channel 4MP@30 fps, 6 Channel 2MP@30 fps AI enabled: 1 Channel 8MP@30 fps, 1 Channel 6MP@30 fps, 1 Channel 5MP@30 fps, 2 Channel 4MP@30 fps, 4 Channel 2MP@30 fps
- Video Display Split
- 1/4
- Record Mode
- General, Motion detection, Intelligent, Alarm
- Video Compression
- Instastream, H.265, H.264+, H.264, MJPEG
- Hard Disk
- 1 SATA port. Each disk can contain up to 20 TB. this limit varies depending on the environment temperature
- General Alarm
- Motion detection, Camera external alarm, PIR alarm
- 4G
- Support
- Intelligent Alarm
- Perimeter protection, IMD+
- Alarm Linkage
- Recording, Snapshot, Buzzer, Log, Preset, Email, Tour
- Audio Compression
- G.711a, G.711u, PCM, G726, AAC
- Audio Input
- 1 Channel RCA
- Audio Output
- 1 Channel RCA
- Protocols
- HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, IP Filter, DDNS, InstaOn, Auto connect, ONVIF (Profile T, Profile S, Profile G), CGI, SDK
- PoE Ports
- 4 Ports, 10/100 Mbps, IEEE 802.3 af/at
- Browser
- Chrome, IE, Safari, Edge, Firefox
- Multi-channel Playback
- Up to 4 Channels
- Playback Mode
- Instant playback, General playback, Event playback, Tag playback, Smart playback
- Backup Mode
- USB device and network
- Interface Ports
- 2 USB (1 front USB 2.0 port, 1 rear USB 2.0 port), 1 HDMI, 1 VGA
- Ethernet
- 1 (10/100 Mbps Ethernet port, RJ-45)
- Power Supply
- 53 VDC, 1.22 A
- Power Consumption
- Total output of NVR is <10W (without HDD) Total output power of PoE is 36W, the maximum output power of a single port is 25.5W
- Operating Temperature
- –10°C to +55°C (14°F to +131°F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Storage Temperature
- –20°C to +60°C (–4°F to +140°F)
- Dimension
- 260 mm × 232.5 mm × 47.6 mm
- Weight
- 850g
