Up to 8 channel IP camera input
Instastream, H.265, H.264+, H.264, MJPEG Decoding
Max. 80/80/60 Mbps incoming/recording/outgoing bandwidth
Support 1 SATA HDD up to 20TB Each, 2 USB Ports, 1 HDMI, 1 VGA, 1 RJ45
- Max. decoding capability
- 6 × 1080p@30 fps
- AI by NVR
- Supports 4 Channel IMD
- AI by Camera
- Supports perimeter protection, IMD
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite
- Processor
- Industrial-grade processor
- User Interface
- Web, Local GUI
- IP Camera Input
- 8 Channels
- Operating System
- Embedded Linux
- Video Compression
- Instastream, H.265, H.264+, H.264, MJPEG
- Resolution
- 5MP, 4MP, 3MP, 1080p, 720p, 960p, D1, CIF, QCIF
- AI by NVR
- IMD
- AI by Camera
- Perimeter protection, IMD
- Perimeter Performance of AI by Camera
- Human and vehicle detection on all channels, supporting up to 4 targets per second
- Ethernet
- 1 (10/100 Mbps Ethernet port, RJ-45)
- IMD+ by NVR
- 4 channels: Secondary filtering for human and motor vehicle, Reducing false alarms caused by leaves, Rain and lighting condition change
- Network Bandwidth
- 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing
- Decoding Capability
- AI disabled: 1 Channel 12MP@30 fps, 1 Channel 8MP@30 fps, 2 Channel 6MP@30 fps, 2 Channel 5MP@30 fps, 3 Channel 4MP@30 fps, 6 Channel 1080p@30 fps AI enabled: 1 Channel 8MP@30 fps, 1 Channel 6MP@30 fps, 1 Channel 5MP@30 fps, 2 Channel 4MP@30 fps, 4 Channel 1080p@30 fps
- Video Output
- 1 HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Playback
- Instant playback, General playback, Event playback, Tag playback, Smart playback
- Protocols
- HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, IP Filter, DDNS, InstaOn, Auto Connect, ONVIF (Profile T, Profile S, Profile G), CGI, SDK
- Backup Mode
- USB device and network
- Audio Compression
- G.711a, G.711u, PCM, G726
- Audio Input
- 1 Channel RCA
- Hard Disk
- 1 SATA port. Each disk can contain up to 20 TB. this limit varies depending on the environment temperature
- Interface Ports
- 2 (1 front USB 2.0 port, 1 rear USB 2.0 port), 1 HDMI, 1 VGA
- Browser
- Chrome, IE, Safari, Edge, Firefox
- Smart Phone
- iOS, Android
- Power Supply
- 12 VDC, 1.5
- Power Consumption
- <10 W (without HDD)
- Operating Temperature
- –10°C to +55°C (14°F to +131°F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Dimension
- 260.0 mm × 232.5 mm × 47.6 mm
