Support up to 1ch@8MP/4ch@1080P decoding
Instastream/H.265/H.264 /H.264 codec decoding
Up to 8MP Resolution Preview and Playback
Max 80Mbps incoming bandwidth
Support 2 SATA HDDs up to 10TB, 2 USB ports (2.0)
HDMI / VGA simultaneous video output
ONVIF Version 2.4 conformance
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS, KVMS Pro
- Processor
- Dual-core embedded processor
- Operating System
- Embedded LINUX
- IP Camera Input
- 8 channel
- Two-way Talk
- 1 channel Input, 1 channel Output, RCA
- User Interface
- GUI
- Video Output
- 1 HDMI, 1 VGA
- Video Resolution
- HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720
- Video Recording
- Max 80 Mbps, 8MP/6MP/5MP/4MP/3MP/1080P/ 720P/ D1&etc.
- Video Display Split
- 1/4/8/9
- Channel
- 8
- Bandwidth Incoming
- 80
- Motion Detection
- MD Zones: 396(22×18).
- Video Loss
- Supports
- Smart Phone
- iPhone, iPad, Android Phone
- Hard Disk
- 2 SATA III ports, up to 10TB Each. The maximum HDD capacity varies with environment temperature
- Trigger Events
- Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips
- Recording Mode
- Manual, Schedule (Continuous, MD (Motion Detection), Alarm, IVS)
- Search Mode
- Time/Date, MD & Exact search (accurate to second)
- Backup Mode
- USB Device / Network
- Playback
- Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection,Digital zoom
- Max User Account
- 128 users
- Record Interval
- 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
- Ethernet
- 1 RJ-45 port (10/100Mbps)
- Interface Ports
- 2 USB Ports(1 Rear USB2.0, 1 Front USB2.0)
- Protocols
- HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, RTSP, IP Search, P2P, ONVIF 2.4, SDK, CGI
- Power Supply
- DC12V/4A
- Power Consumption
- <3W (without HDD)
- Working Temp
- -10 ~+55°C / 10~90%RH / 86~106kpa
- Dimension
- 375mm x 275mm x 53mm
- Weight
- 1.5kg (without HDD)
