Up to 16 Channel IP Camera input
Instastream, H.265, H.264+, H.264, MJPEG
Max. 144/144/72 Mbps incoming/recording/outgoing bandwidth
Support 2 SATA HDDs up to 20TB, 2 USB ports(2.0)
HDMI / VGA simultaneous video output
- AI by Recorder
- Support 4 channel SMD
- AI by Camera
- Support perimeter protection and SMD
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite
- Processor
- Industrial-grade processor
- Operating System
- Embedded LINUX
- IP Camera Input
- 16 channel
- User Interface
- Web, Local GUI
- AI by Recorder
- SMD
- AI by Camera
- Perimeter protection, SMD
- Perimeter Performance of AI by Camera
- All channels (4 targets/s)
- Video Output
- 1 HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Video Compression
- H.265, H.264+, H.264, MJPEG
- Encode Strategy
- Instastream
- Decoding Capability
- AI disabled: 1 channel 12 MP@30 fps, 1 channel 8 MP@30 fps, 2 channel 6 MP@30 fps, 2 channel 5 MP@30 fps, 3 channel 4 MP@30 fps, 6 channel 1080p@30 fps AI enabled: 1 channel 8 MP@30 fps, 1 channel 6 MP@30 fps, 1 channel 5 MP@30 fps, 2 channel 4 MP@30 fps, 4 channel 1080p@30 fps
- Video Resolution
- 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 2MP, 720p, 960p, D1, CIF, QCIF
- Video Display Split
- 1/4/8/9/16
- SMD Plus by NVR
- 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
- SMD Plus by Camera
- All channels (8 targets/s)
- Network Bandwidth
- AI disabled: 144 Mbps incoming, 144 Mbps recording and 72 Mbps outgoing AI enabled: 72 Mbps incoming, 72 Mbps recording and 36 Mbps outgoing
- Protocols
- HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, IP Filter, DDNS, InstaOn, Auto Registration, ONVIF 23.12(Profile T, Profile S, Profile G), CGI, SDK
- Abnormality Alarm
- Error (No disk, Disk error, Low space, Low quota space, Network disconnection, IP conflict, MAC conflict), Video loss, Video tampering, Camera offline
- Intelligent Alarm
- Perimeter protection; SMD+
- General Alarm
- Motion detection, Camera external alarm, PIR alarm
- Alarm Linkage
- Recording, Snapshot, Buzzer, Log, Preset, Email, Tour
- Audio Input
- 1 channel RCA
- Audio Output
- 1 channel RCA
- Audio Compression
- G.711a, G.711u, PCM, G726, AAC
- Hard Disk
- 2 SATA ports. Each disk can contain up to 20 TB. this limit varies depending on the environment temperature
- Multi-channel Playback
- Up to 16 channels
- Record Mode
- General, Motion detection, Intelligent, Alarm
- Playback Mode
- Instant playback, General playback, Event playback, Tag playback, Smart playback
- Interface Ports
- 2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
- Backup Method
- USB device and network
- Smart Phone
- iOS, Android
- Ethernet
- 1 (10/100/1000 Mbps Ethernet port, RJ-45)
- Browser
- Chrome, IE, Safari, Edge, Firefox
- Power Supply
- 12 VDC, 4 A
- Power Consumption
- ≤ 10 W (without HDD)
- Operating Temperature
- -10 °C to +55 °C (14 °F to +131 °F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Storage Temperature
- -20 °C to +60 °C (–4 °F to +140 °F)
- Dimensions
- 375.0 mm × 282.9 mm × 53.0 mm
- Weight
- 1490 g (without HDD)
