English
Up to 16 channel IP camera input
Smart Instastream,H.265,Smart H.264+,H.264 and MJPEG decoding
Max. 160/160/80 Mbps incoming/recording/outgoing bandwidth
2 SATA ports. Each disk can contain up to 20TB, 2 USB Ports
Supports IP cameras with a resolution up to 12MP
AI by NVR supports 4-channel SMD Plus
AI by Camera supports face detection and recognition, perimeter protection, SMD Plus, people counting, stereo analysis and heat map
Supports EPTZ, and one-click arming and disarming
Support 16 PoE Ports
Perimeter Performance of AI by Camera (Number of Channels): 6 channels
Face Detection Performance of AI by Camera (Number of Channels): 6 channels
Face Recognition Performance of AI by Camera (Number of Channels): 6 channels
- Max. decoding capability
- 8 × 1080p@30fps or 2 × 8MP@30fps.
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro
- Processor
- Industrial-grade processor
- IP Camera Input
- 16 channel
- Operating System
- Embedded LINUX
- Operation Interface
- Web, Local GUI
- AI by NVR
- SMD Plus
- AI by Camera
- Face detection
- face recognition
- perimeter protection
- SMD Plus
- people counting
- stereo analysis
- heat map
- Face Attributes
- Gender; age group; glasses; expressions; face mask; beard
- SMD Plus by NVR
- 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
- SMD Plus by Camera
- 6 channels
- Video Output
- 1 HDMI, 1 VGA Simultaneous HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous: HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Compression
- H.265; Smart H.264+; H.264
- Encode Strategy
- Instastream
- Network Bandwidth
- AI disabled: 160Mbps incoming, 160Mbps recording and 80Mbps outgoing AI enabled: 80Mbps incoming, 80Mbps recording and 60Mbps outgoing
- Resolution
- 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF; QCIF
- Decoding Capability
- AI disabled: 1-channel 12 MP@30 fps
- 2-channel 8 MP@30 fps
- 3-channel 5 MP@30 fps
- 4- channel 4 MP@30 fps
- 8-channel 1080p@30 fps AI enabled: 1-channel 12 MP@30 fps
- 1- channel 8 MP@30 fps
- 2-channel 5 MP@30 fps
- 3-channel 4 MP@30 fps
- 7-channel 1080p@30fps
- Multi-screen Display
- Main Screen: 1/4/8/9/16 Sub Screen: 1/4/8/9/16
- Intelligent Alarm
- Face detection
- face recognition
- perimeter protection
- SMD Plus
- people counting
- stereo analysis
- heat map
- General Alarm
- Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm
- Anomaly Alarm
- Camera disconnection
- storage error
- disk full
- IP conflict
- MAC conflict
- login locked
- and cybersecurity exception
- Alarm Linkage
- Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email
- Audio Compression
- G.711a; G.711u; PCM; G726
- Audio Input
- 1-channel RCA
- Audio Output
- 1-channel RCA
- Alarm Input
- 4 Channel
- Alarm Output
- 2 channels (1-channel 12 V 1 A output)
- Record Mode
- General, motion detection; intelligent; alarm
- Smart Phone
- iPhone, iPad, Android Phone
- Hard Disk
- 2 SATA ports. Each disk can contain up to 20TB. This limit varies depending on the environment temperature.
- Browser
- Chrome; IE; Safari; Edge; Firefox
- Disk Group
- Support
- Multi-channel Playback
- Up to 16 channels
- Playback Mode
- Instant playback, general playback, event playback, tag playback, smart playback
- Backup
- USB device and network
- Interface Ports
- 2 USB ports (1 front USB 2.0 port, 1 rear USB 2.0 port), 1 RS232 Port, 1 HDMI, 1 VGA Port
- Ethernet
- 1 (10/100/1000 Mbps Ethernet port, RJ-45)
- PoE
- 16 ports, 10/100 Mbps, IEEE 802.3 af/at
- Protocols
- HTTP
- HTTPS
- TCP/IP
- IPv4
- IPv6
- UDP
- NTP
- DHCP
- DNS
- SMTP
- UPnP
- IP Filter
- FTP
- DDNS
- SNMP
- Alarm Server
- InstaOn cloud
- Auto Registration
- IP Search
- ONVIF 22.12(Profile T
- Profile S
- Profile G)
- CGI
- Power Supply
- 100–240 VAC, 50/60 Hz
- Power Consumption
- Total output of NVR is <10 W (without HDD) Total output power of PoE is 130W,the maximum output power of a single port is 25.5W
- Operating Temperature
- -10 °C to +55 °C (14 °F to +131 °F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Storage Temperature
- -20 °C to +60 °C (–4 °F to +140 °F)
- Dimension
- 375.0 mm × 327.9 mm × 53.0 mm (14.76
- Weight
- 2.60kg
