Up to 16 channel IP camera input
Smart Instastream/H.265/H.264 /MJPEG
Up to 12Mp resolution preview and playback
Max. 160/160/80 Mbps incoming/recording/outgoing bandwidth
Support 2 SATA HDDs up to 20TB, 2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
HDMI / VGA simultaneous video output
Support Multi-brand network cameras
ONVIF Version 2.4 conformance
- Max. decoding capability
- 8 × 1080p@30 fps, 2 × 8 MP@30 fps
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS, KVMS Pro
- Processor
- Industrial-grade embedded processor
- Operating System
- Embedded LINUX
- Two-way Talk
- 1 × RCA input ; Audio Input/ Audio Output
- User Interface
- GUI
- Video Output
- 1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA and HDMI
- Channel
- 16 channel
- Video Loss
- Supports
- Alarm Input
- 4 Channels
- Smart Phone
- iPhone, iPad, Android Phone
- Hard Disk
- 2 SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature.
- Recording Mode
- Manual record; alarm recording; SMD recording; smart recording
- Search Mode
- Time /Date, MD and Exact Search (accurate to second),
- Backup Mode
- USB Device/Network
- Playback
- Play/pause/stop/slow/quick/backward/by frame Full screen, backup (video clip/file), partial zoom in, and audio on/off
- Ethernet
- 1 RJ-45 port (10/100M/1000M)
- Interface Ports
- 2 USB Ports (1 × front USB2.0; 1 × back USB2.0)
- Protocols
- HTTP
- HTTPS
- TCP/IP
- IPv4
- IPv6
- UDP
- NTP
- DHCP
- DNS
- SMTP
- UPnP
- IP Filter
- FTP
- DDNS
- SNMP
- Alarm Server
- P2P
- Auto Registration
- IP Search (Supports IP camera, DVR, NVS, etc.)
- Power Supply
- DC12V/1.5A
- Power Consumption
- < 10 W (HDD not included)
- Working Temp
- –20 °C to +50 °C (–4 °F to +140 °F)
- Dimension
- 375.0 mm × 282.9 mm × 53.0 mm
- Weight
- 1.49 kg
