Up to 16 channel IP camera input
Instastream, H.265, H.264+, H.264, MJPEG
Support 4 SATA ports, up to 16TB each, 2 USB (1 front USB 2.0 port, 1 rear USB 3.0 port), 1 RS232, 1 RS485
1 HDMI, 1 VGA Simultaneous/ Heterogeneous video output
- AI by Recorder
- 1 Channel face detection and Recognition, 2 Channel perimeter protection, up to 10 face databases and 20,000 face images, 4 Channel SMD Plus
- AI by Camera
- Face detection and Recognition, Perimeter protection, SMD Plus, ANPR, People counting, Stereo analysis, Heat map
- AI disabled
- 256 Mbps incoming, AI enabled: 180 Mbps incoming
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite
- Processor
- Industrial-grade processor
- IP Camera Input
- 16 Channels
- Operating System
- Embedded LINUX
- User Interface
- Web, Local GUI
- Perimeter Performance AI by NVR
- 2 channels, 10 IVS rules for each channel
- Perimeter Performance of AI by Camera
- All channels (8 targets/s)
- Face Detection AI by NVR
- 1 Channel (up to 12 face images/s each channel)
- Video Output
- 1 HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Abnormality Alarm
- Camera disconnection, Storage error, Disk full, IP conflict, MAC conflict, Login locked, Cybersecurity exception
- Face Recognition AI by NVR
- 8 Channel FD (by camera) + FR (by NVR), image stream: 12 face images/s 1 Channel FD (by NVR) + FR (by NVR), video stream: 12 face images/s
- Face Recognition AI by Camera
- All Channels (8 targets/s)
- Network Bandwidth
- AI disabled: 256 Mbps incoming, 256 Mbps recording and 256 Mbps outgoing AI enabled: 180 Mbps incoming, 180 Mbps recording and 180 Mbps outgoing
- Video Display Split
- 1st Screen: 1/4/8/9/16; 2nd Screen: 1/4/8/9
- ANPR by Camera (Number of Channels)
- All Channels (4 targets/s)
- License Plate Database Capacity
- 1. Create up to 20,000 plate numbers; 2. Blocklist and allowlist
- Audio Input
- 1 Channel RCA
- Audio Output
- Audio Output
- Video Resolution
- 8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 2MP, 960p, 720p, D1, CIF
- Video Compression
- Instastream, H.265, H.264+, H.264, MJPEG
- Alarm Input
- 16 Channel
- Alarm Output
- 4 Channels
- Disk Group
- Support
- Hard Disk
- 4 SATA ports, up to 16 TB each. The maximum HDD capacity varies with environment temperature
- Alarm Linkage
- Record, Snapshot, IPC external alarm output, Audio, Buzzer, Log, Preset, Email
- Multi-channel Playback
- Up to 16 Channels
- Interface Ports
- 2 (1 front USB 2.0 port, 1 rear USB 3.0 port), 1 HDMI, 1 VGA, 1 RS232,
- Ethernet
- 2 (10/100/1000 Mbps Ethernet port, RJ-45)
- Protocols
- HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, P2P, auto register, ONVIF 22.06(Profile T, Profile S, Profile G), CGI, SDK
- Backup Method
- USB device and network
- SMD Plus by NVR
- 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, Rain and lighting condition change
- Smart Phone
- iOS, Android
- Browser
- Chrome, IE9 and later, Firefox
- Power Supply
- 100–240 VAC, 50-60Hz
- Power Consumption
- <10 W (without HDD)
- Operating Temperature
- –10 °C to +55 °C (14 °F to +131 °F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Storage Temperature
- –20 °C to +60 °C (–4 °F to +140 °F)
- Dimension
- 440.0 mm × 415.6 mm x 76.0 mm
- Weight
- 4.25 kg
