Up to 32 channel IP camera input
Instastream, H.265, H.264 , H.264, MJPEG Decoding
Max. 160/128/60 Mbps Incoming/ Recording/ Outgoing Bandwidth
Support 2 SATA HDDs up to 20TB Each, 2 USB Ports
HDMI / VGA simultaneous video output
Support Multi-brand network cameras
- Max. decoding capability
- 8 × 1080p@30 fps or 2 × 8 MP@30 fps
- AI by Camera
- Face detection and recognition, Perimeter protection, SMD Plus, People counting, Stereo analysis and heat map
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite
- Processor
- Industrial-grade processor
- Operating System
- Embedded LINUX
- IP Camera Input
- 32 channel
- User Interface
- Web, Local GUI
- AI by NVR
- SMD Plus
- Perimeter Performance of AI by Camera
- 6 Channels
- Video Output
- 1 HDMI, 1 VGA Simultaneous: HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous: HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Face Attributes
- Gender, Age group, Glasses, Expressions, Face mask, Beard
- Abnormality Alarm
- Camera disconnection, Storage error, Disk full, IP conflict, MAC conflict, Login locked, Cybersecurity exceptio
- SMD Plus by NVR
- 2 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
- Face Detection AI by Camera
- 6 Channels
- Resolution
- 4 MP, 3 MP, 2MP, 960p, 720p, D1, CIF, QCIF
- Video Compression
- Instastream; H.265, H.264+, H.264
- Network Bandwidth
- AI disabled: 160 Mbps incoming, 128 Mbps recording and 60 Mbps outgoing AI enabled: 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing
- Smart Phone
- iPhone, iPad, Android Phone
- Disk Group
- Support
- Video Display Split
- AI disabled: Main Screen: 1/4/8/9/16/25/36, Sub Screen: 1/4/8/9/16 AI enabled: Main Screen: 1/4/8/9/16, Sub Screen: 1/4/8/9/16
- Audio Input
- 1 Channel RCA
- Audio Output
- 2 Channel RCA
- Audio Compression
- G.711a, G.711u, PCM,
- Hard Disk
- 2 SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperatur
- Browser
- Chrome, IE, Safari, Edge, Firefox
- Multi-channel Playback
- Up to 16 Channels
- Playback
- Instant playback, General playback, Event playback, Tag playback, Smart playback
- Backup Mode
- USB device and Network
- Interface Ports
- 2 (1 front USB 2.0 port, 1 rear USB 2.0 port), 1 HDMI, 1 VGA
- Ethernet
- 1 (10/100/1000 Mbps Ethernet port, RJ-45)
- Protocols
- HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, InstaOn, Auto Registration, ONVIF 22.12(Profile T, Profile S, Profile G), CGI, SDK
- Power Supply
- 12 VDC, 2 A
- Power Consumption
- Total output of NVR is <10 W(without HDD)
- Operating Temperature
- –10 °C to +55 °C (14 °F to +131 °F)
- Storage Temperature
- –10 °C to +55 °C (14 °F to +131 °F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Dimensions
- 375.0 mm × 282.9 mm × 53.0 mm
- Weight
- 1.49 kg
