Up to 32 channel IP camera input
H.265, H.264, MJPEG
Up to 16Mp Video Resolution
Support 4 SATA ports, up to 16TB each, 3 USB (1 front USB 2.0 port, 2 rear USB3.0 ports)
1 HDMI, 1 VGA simultaneous video output
Support ONVIF
Support SMD Plus
Perimeter Performance AI by NVR (Number of Channels): 2 channels, 10 IVS rules for each channel
Perimeter Performance of AI by Camera (Number of Channels): 16 channels
Face Detection Performance of AI by Recorder (Number of Channels): 2 channels (up to 12 face images/s each channel)
Face Detection Performance of AI by Camera (Number of Channels): 8 channels
Face Recognition Performance of AI by Camera (Number of Channels): 16 channels
Metadata Performance of AI by Camera (Number of Channels): 16 channels
- AI disabled
- 2-channel 16 MP@30 fps, AI enabled: 1-channel 16 MP@30 fps
- AI disabled
- 256 Mbps incoming, AI enabled: 180 Mbps incoming
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite
- Processor
- Industrial-grade processor
- IP Camera Input
- 32 Channel
- Operating System
- Embedded LINUX
- User Interface
- Web, Local GUI
- Video Output
- 1-channel VGA, 1-channel HDMI video output. HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 *Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable.
- Compression
- H.265, H.264, MJPEG
- Encode Strategy
- Instastream
- Decoding Capability
- AI disabled: 2-channel 16 MP@30 fps, 2-channel 12 MP@30 fps, 4-channel 8 MP@30 fps, 6-channel 5 MP@30 fps, 8-channel 4 MP@30 fps, 16-channel 1080p@30 fps AI enabled: 1-channel 16 MP@30 fps, 2-channel 12 MP@30 fps, 3-channel 8 MP@30 fps, 4-channel 5 MP@30 fps, 6-channel 4 MP@30 fps, 12-channel 1080p@30 fps
- AI by NVR
- Face detection; face recognition; perimeter protection; SMD Plus
- Resolution
- 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF
- Network Bandwidth
- 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF
- Video Display Split
- Main screen: 1/4/8/9/16/25 Sub screen: 1/4/8/9/16
- Face Attributes
- Gender; age group; glasses; expressions; face mask; beard
- Face Database Capacity
- Up to 20 face databases with 10,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
- SMD Plus by NVR
- 8 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
- SMD Plus by Camera
- 16 channels
- Human Attributes
- Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella
- License Plate Database Capacity
- 1. Create up to 20,000 plate numbers. 2. Blocklist and allow list
- Alarm Linkage
- Record, snapshot, IPC external alarm output, audio, buzzer, log, preset, email
- Audio Input
- 1-channel RCA
- Audio Output
- 2-channel RCA
- Audio Compression
- G.711a, G.711u, PCM, G726, AAC
- Disk Group
- Support
- Hard Disk
- 4 SATA ports, up to 16TB each. The maximum HDD capacity varies with environment temperature
- Multi-channel Playback
- Up to 16 channels
- Record Mode
- General, motion detection; intelligent; alarm; POS
- Playback Mode
- Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
- Smart Phone
- iPhone, iPad, Android Phone
- Interface Ports
- 3(1 front USB 2.0 port, 2 rear USB 3.0 ports), 1 HDMI, 1 VGA, 1 RS232, 1 eSATA Port, 1 RS485
- Protocols
- HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, IP Search, DH, Multicast, InstaOn cloud, Auto Registration, ONVIF 21.12(Profile T, Profile S, Profile G)
- Ethernet
- 2 (10/100/1000 Mbps Ethernet port, RJ-45)
- Power Supply
- 100–240 VAC, 50-60 Hz
- Power Consumption
- ≤ 10 W (without HDD)
- Operating Temperature
- -20 °C to +60 °C (–4 °F to +140 °F)
- Operating Humidity
- 10%–93% (RH)
- Storage Temperature
- -20 °C to +60 °C (–4 °F to +140 °F)
- Dimensions
- 440.0 mm × 415.1 mm x 70.0 mm
- Weight
- 4250 g (without HDD)
