Up to 32 channel IP camera input
Max. 384 Mbps incoming/recording/outgoing bandwidth
Instastream/H.265/Smart H.264+/H.264/MJPEG codec decoding
Support 2 SATA HDDs up to 16TB Each, 2 USB Ports (1 USB 3.0)
HDMI/ VGA simultaneous video output
Support Multi-brand network cameras
Perimeter Performance AI by NVR (Number of Channels): 4 channels, 10 IVS rules for each channel
Perimeter Performance of AI by Camera (Number of Channels): 16 channels
Face Detection Performance of AI by NVR (Number of Channels): 2 channels (up to 12 face images/s each channel)
Face Detection Performance of AI by Camera (Number of Channels): 16 channels
Face Recognition Performance of AI by NVR (Number of Channels): 1. 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s 2. 2-channel FD (by recorder) + FR (by recorder), video stream: 12 face images/s
Metadata Performance of AI by Camera (Number of Channels): 8 channels
- AI by Recorder
- 2-channel face detection or recognition/ 4-channel perimeter protection/ 8- channel SMD Plus.
- AI by camera
- Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting.
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro
- Processor
- Industrial-grade processor
- IP Camera Input
- 32 channel
- Operating System
- Embedded LINUX
- User Interface
- Web, Local GUI
- Video Output
- 1-channel VGA, 1-channel HDMI video output. Heterogeneous video source output for HDMI and VGA Supports 4K display
- Compression
- H.265; Smart H.264+; H.264; MJPEG
- Encode Strategy
- Instastream
- Decoding Capability
- AI disabled: 2-channel 32 MP@20 fps
- 2-channel 24 MP@20 fps
- 4-channel 16 MP@30 fps
- 5- channel 12 MP@30fps
- 8-channel 8 MP@30 fps
- 12-channel 5 MP@30fps
- 16-channel 4 MP@30 fps
- 32-channel 1080p@30fps AI enabled: 1-channel 32 MP@20 fps
- 1-channel 24 MP@20 fps
- 2-channel 16 MP@30 fps
- 4-channel 12 MP@30 fps
- 4-channel 8 MP@30 fps
- 8-channel 5 MP@30 fps
- 12-channel 4 MP@30 fps
- 24-channel 1080p@30fps
- AI by NVR
- Face detection; face recognition; perimeter protection; SMD Plus
- AI by Camera
- Face detection
- face recognition
- video metadata (human, motor vehicles, and non-motor vehicles)
- perimeter protection
- SMD Plus
- stereo analysis
- crowd distribution
- people counting
- ANPR
- vehicle density
- heat map
- Resolution
- 32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1; CIF; QCIF
- Network Bandwidth
- AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
- Video Display Split
- Main screen: 1/4/8/9/16/25/36; Sub screen: 1/4/8/9/16
- Face Attributes
- Gender; age group; glasses; expressions; face mask; beard
- Face Database Capacity
- Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
- Face Recognition Performance of AI by Camera
- 16 channels
- SMD Plus by NVR
- 8 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
- SMD Plus by Camera
- 16 channels
- Human Attributes
- Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella
- Motor Vehicle Attributes
- License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location
- Non-motor Vehicle Attributes
- Vehicle model, vehicle color, number of persons, helmet
- ANPR by Camera (Number of Channels)
- 8 channels
- License Plate Database Capacity
- 1. Create up to 20,000 plate numbers. 2. Blocklist and allow list
- Intelligent Alarm
- Face detection
- perimeter protection
- face recognition
- video metadata (human, motor vehicles, and non-motor vehicles)
- SMD Plus
- stereo analysis
- crowd distribution
- people counting
- ANPR
- vehicle density
- heat map
- Anomaly Alarm
- Camera offline
- storage error
- disk full
- IP conflict
- MAC conflict
- login lock
- abnormal behavior of fan
- cyber security exception
- General Alarm
- Motion detection; privacy masking; local alarm
- Alarm Linkage
- Record
- snapshot (panoramic)
- local alarm output
- IPC external alarm output
- access controller
- audio
- buzzer
- log, preset
- Audio Input
- 1-channel RCA
- Audio Output
- 1-channel RCA
- Audio Compression
- G.711a; G.711u; PCM; G726
- Disk Group
- Support
- Alarm Input
- 4 channel
- Alarm Output
- 2 channel
- Hard Disk
- 2 SATA ports, up to 16TB. The maximum HDD capacity varies with environment temperature
- Multi-channel Playback
- Up to 16 channels
- Record Mode
- General, motion detection; intelligent; alarm; POS
- Browser
- Chrome, IE9 or later, Firefox
- Playback Mode
- Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection)
- Smart Phone
- iPhone, iPad, Android Phone
- Backup Mode
- USB Device/Network
- Interface Ports
- 2 USB Ports (1 Rear USB 3.0, 1 Front USB 2.0), 1 RS232, 1 RS485
- Protocols
- HTTP
- HTTPS
- TCP/IP
- IPv4/IPv6
- RTSP
- UDP
- SNMP
- NTP
- DHCP
- DNS
- SMTP
- UPnP
- IP Filter
- PPPoE
- FTP
- DDNS
- Alarm Server
- IP Search, Multicast
- InstaOn cloud
- Auto Registration
- ONVIF 21.12(Profile T
- Profile S
- Profile G)
- CGI
- SDK
- Ethernet
- 1 x (10/100/1000 Mbps Ethernet port, RJ-45)
- Power Supply
- 12 VDC, 4Amp
- Power Consumption
- ≤ 10 W (without HDD)
- Operating Temperature
- -10 °C to +55 °C (14 °F to +131 °F)
- Operating Humidity
- 10%–93% (RH)
- Storage Temperature
- -20 °C to +60 °C (–4 °F to +140 °F)
- Dimensions
- 375.0 mm × 284.4 mm x 56.0mm (14.76
- Weight
- 1.57kg (without HDD)
