Up to 32 channel IP camera input
Max. 384 Mbps incoming/recording/outgoing bandwidth
Instastream/H.265/Smart H.264+/H.264/MJPEG codec decoding
Support 4 SATA HDDs up to 16TB Each, 3 USB Ports (2 USB 3.0)
2 HDMI/ 2 VGA simultaneous video output
Support Multi-brand network cameras
Perimeter Performance AI by NVR (Number of Channels): 4 Channels, 10 IVS rules for each Channel
Perimeter Performance of AI by Camera (Number of Channels): All Channels (16 targets/s)
Face Detection Performance of AI by Recorder (Number of Channels): 2 Channels (up to 12 face images/s each Channel)
Face Detection Performance of AI by Camera (Number of Channels): 16 Channels
Face Recognition Performance of AI by NVR (Number of Channels): 1. 16 Channel FD (by camera) + FR (by NVR), image stream: 16 face images/s 2. 2 Channel FD (by NVR) + FR (by NVR), video stream: 12 face images/s
Face Recognition Performance of AI by Camera (Number of Channels): 16 Channels
Metadata Performance of AI by Camera (Number of Channels): 8 Channels
- AI by Recorder
- 2-channel face detection or recognition/ 4-channel perimeter protection/ 8- channel SMD Plus.
- AI by camera
- Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, stereo analysis, heat map, and people counting
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro
- Processor
- Industrial-grade processor
- IP Camera Input
- 32 Channel
- Operating System
- Embedded LINUX
- User Interface
- Web, Local GUI
- Video Output
- 2 VGA:1920 × 1080, 1280 × 1024, 1280 × 720 2 HDMI:3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous video source output for HDMI1 and HDMI2 Simultaneous video source output for VGA1 and HDMI1 Simultaneous video source output for VGA2 and HDMI2
- Video Compression
- Instastream, H.265, H.264+, H.264, MJPEG
- Decoding Capability
- AI disabled: 2 Channel 32 MP@25 fps, 2 Channel 24 MP@25 fps, 4 Channel 16 MP@30 fps, 5 Channel 12 MP@30 fps, 8 Channel 8 MP@30 fps, 10 Channel 6 MP@30 fps, 12 Channel 5 MP@30 fps, 16 Channel 4 MP@30 fps, 32 Channel 1080p@30 fps AI enabled: 1 Channel 32 MP@25 fps
- 1 Channel 24 MP@25 fps
- 2 Channel 16 MP@30 fps, 4 Channel 12 MP@30 fps, 6 Channel 8 MP@30 fps, 8 Channel 6 MP@30 fps, 8 Channel 5 MP@30 fps, 12 Channel 4 MP@30 fps, 24 Channel 1080p@30 fps
- AI by NVR
- Face detection, Face recognition, Perimeter protection, SMD Plus
- AI by Camera
- Face detection, Face recognition, Video metadata (Human, Motor vehicles, Non-motor vehicles), Perimeter protection, SMD Plus, Stereo analysis, Crowd distribution, People counting, ANPR, Vehicle density, Heat map
- IntelliCheck AI by Camera + Recorder
- Max. 32 Channel, 1 combined event per Channel/s
- Resolution
- 32 MP, 24 MP, 16 MP, 12 MP, 8 MP, 6 MP, 5 MP, 4 MP, 2 MP, 720p, 960p, D1, CIF, QCIF
- Network Bandwidth
- AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
- Video Display Split
- Main screen: 1/4/8/9/16/25/36, Sub screen: 1/4/8/9/16
- Face Attributes
- Gender, Age group, Glasses, Expressions, Face mask, Beard
- Face Database Capacity
- Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image
- SMD Plus by NVR
- 8 Channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
- SMD Plus by Camera
- All Channels (32 targets/s)
- Human Attributes
- Top color, Top type, Bottom color, Bottom type, Hat, Bag, age, Gender and Umbrella
- Motor Vehicle Attributes
- License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location
- Non-motor Vehicle Attributes
- Vehicle model, Vehicle color, Number of persons, Helmet
- ANPR by Camera (Number of Channels)
- All Channels (8 Targets/s)
- License Plate Database Capacity
- 1. Create up to 20,000 plate numbers, 2. Blocklist and allowlist
- Abnormality Alarm
- Camera offline, Storage error, Disk full, IP conflict, MAC conflict, Login lock, Abnormal behavior of fan, Cyber security exception
- Intelligent Alarm
- Face detection, Perimeter protection, Face recognition, Video metadata (Human, Motor vehicles, Non-motor vehicles), SMD Plus, Stereo analysis, Crowd distribution, People counting, ANPR, Vehicle density, Heat map
- General Alarm
- Motion detection, Local alarm, Alarm box, Camera external alarm, Network alarm, Scene changing, PIR alarm, Thermal alarm
- Alarm Linkage
- Record, Snapshot (panoramic), Local alarm output, IPC external alarm output, Access controller, Audio, Buzzer, Log, Preset, Ema
- Audio Input
- 1 Channel RCA
- Audio Output
- 2 Channel RCA
- Audio Compression
- G.711a, G.711u, PCM, G726, AAC
- Disk Group
- Support
- Alarm Input
- 16 Channel
- Alarm Output
- 6 Channels (1 Channel 12 V 1 A output)
- Hard Disk
- 4 SATA ports, each disk can contain up to 20 TB. This limit varies depending on the environment temperature
- Multi-channel Playback
- Up to 16 Channels
- Record Mode
- General, Motion detection, Intelligent, Alarm, POS
- Backup Method
- USB device and network
- Playback Mode
- Instant playback, General playback, Event playback, Tag playback, Smart playback (face and motion detection
- Interface Ports
- 3(1 front USB 2.0 port, 2 rear USB 3.0 ports), 1 RS232, 1 eSATA Port, 1 RS485 (half-duplex serial communication)
- Protocols
- HTTP, HTTPS, TCP/IP, IPv4, UDP, NTP, DHCP, DNS, SMTP, UPnP, DDNS, Alarm Server, Multicast, P2P, Auto Registration, iSCSI, ONVIF 23.12(Profile T, Profile S, Profile G), CGI, SDK
- Network Mode
- Multi-address mode, Load balance, Fault tolerance and other network port binding modes
- Smart Phone
- iPhone, iPad, Android Phone
- Ethernet
- 2 (10/100/1000 Mbps Ethernet port, RJ-45)
- Browser
- Chrome, IE, Safari, Edge, Firefox
- Power Supply
- 100–240 VAC, 50-60 Hz
- Power Consumption
- Total output of NVR is ≤ 13 W (without HDD)
- Operating Temperature
- -10 °C to +55 °C (14 °F to +131 °F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Storage Temperature
- -20 °C to +60 °C (–4 °F to +140 °F)
- Dimensions
- 440.0 mm × 415.1 mm x 70.0 mm
- Weight
- 4.74 kg (without HDD)
