Up to 32 channel IP camera input
Instastream, H.265, H.264 , H.264, MJPEG Decoding
Up to 16MP Video Resolution
Support 4 SATA ports, up to 16TB, 2 USB (1 front USB 2.0 Port, 1 rear USB 3.0 Port)
1 HDMI, 1 VGA simultaneous video output
Support ONVIF 22.06
Support SMD Plus
- AI Disabled
- 2 Channel 16 MP@30 fps, AI enabled: 1 Channel 16 MP@30 fps
- AI disabled
- 256 Mbps incoming, AI enabled: 180 Mbps incoming
- Mobile Software
- iCMOB, gCMOB
- Processor
- Industrial-grade processor
- IP Camera Input
- 32 channels
- Operating System
- Embedded LINUX
- User Interface
- Web, Local GUI
- AI by NVR
- Face detection, Face recognition, Perimeter protection, SMD Plus
- Perimeter Performance AI by NVR
- 2 channels, 10 IVS rules for each channel
- Face Detection AI by NVR
- 1 channel (up to 12 face images/s each Channel)
- Video Output
- 1 HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720; 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- Face Recognition AI by NVR
- 8-channel FD (by camera) + FR (by recorder), image Stream: 12 face images/s 1-channel FD (by recorder) + FR (by recorder), video Stream: 12 face images/s
- Network Bandwidth
- AI disabled: 256 Mbps incoming, 256 Mbps recording and 256 Mbps outgoing AI enabled: 180 Mbps incoming, 180 Mbps recording and 180 Mbps outgoing
- Encode Strategy
- Instastream, H.264+
- Video Compression
- H.265, H.264, MJPEG
- ANPR by Camera (Number of Channels)
- 6 Channels
- Video Display Split
- Main screen: 1/4/8/9/16/25/36 Sub screen: 1/4/8/9/16
- Decoding Capability
- AI disabled: 2-channel 16 MP@30 fps
- 2-channel 12 MP@30 fps
- 4-channel 8 MP@30 fps
- 6- channel 5 MP@30 fps
- 8-channel 4 MP@30 fps
- 16-channel 1080p@30 fps AI enabled: 1-channel 16 MP@30 fps
- 2-channel 12 MP@30 fps
- 3-channel 8 MP@30 fps
- 4- channel 5 MP@30 fps
- 6-channel 4 MP@30 fps
- 12-channel 1080p@30 fps
- Record Mode
- General, Motion detection, Intelligent, Alarm
- Resolution
- 4 MP, 3 MP, 2MP, 960p, 720P, D1, CIF
- Disk Group
- Support
- Hard Disk
- 4 SATA ports, up to 16 TB. The maximum HDD capacity varies with environment temperature
- Playback Mode
- Instant playback, General playback, Event playback, Tag Playback, Smart layback
- Multi-channel Playback
- Up to 16 Channels
- Interface Ports
- 2 (1 front USB 2.0 port, 1 rear USB 3.0 port), 1 HDMI, 1 VGA, 1 RS232, 1 RS485
- Ethernet
- 2 (10/100/1000 Mbps Ethernet port, RJ-45)
- Protocols
- HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, UDP
- SMTP
- NTP
- DHCP
- DNS
- IP Filter
- PPPoE
- DDNS
- FTP
- Alarm Server
- IP Search (Support Dahua IP camera
- DVR
- NVS
- etc.)
- InstaOn
- auto register, ONVIF 22.06(Profile T
- Profile S
- Profile G)
- CGI
- SDK
- Backup Method
- USB device and network
- Alarm Input
- 16 channel
- Alarm Output
- 16 channels
- Audio Compression
- G.711a, G.711u, PCM, G726, AAC
- Smart Phone
- iPhone, iPad, Android Phone
- Browser
- Chrome, IE9 and later, Firefox
- Power Supply
- 100–240 VAC, 50-60Hz
- Power Consumption
- <10 W (without HDD)
- Operating Temperature
- –10 °C to +55 °C (14 °F to +131 °F)
- Operating Humidity
- 10%–93% (RH)
- Storage Temperature
- –20 °C to +60 °C (–4 °F to +140 °F)
- Dimensions
- 440.0 mm × 415.6 mm x 76.0 mm
- Weight
- 4.25 kg
