Up to 64 channel IP camera input
Max. 512/512/512 Mbps Incoming/ Recording/ Outgoing bandwidth
Support redundant power, RAID 0/1/5/6/10, N+M cluster
Support 8 SATA HDDs up to 20TB Each, 4 USB Ports
2 HDMI/ 2 VGA simultaneous video output
Perimeter Performance AI by NVR (Number of Channels): 24 Channels, 10 IVS rules for each channel
Face Detection Performance of AI by Camera (Number of Channels): Human and vehicle detection on all channels, supporting up to 32 targets per second
- Max. Decoding capability
- 32 × 1080p@30fps
- AI by Recorder
- Supports 8 channel face detection and recognition, up to 20 face databases and 200,000 face images, 8 Channel metadata, 24 Channel perimeter protection, 32 Channel IMD+ (Intelligent motion detection)
- AI by Camera
- Supports face detection and recognition, perimeter protection, IMD+, Metadata, ANPR, Stereo analysis, Heat map, and people counting.
- Mobile Software
- iCMOB, gCMOB
- Processor
- Industrial-grade processor
- Operating System
- Embedded Linux
- IP Camera Input
- 64 Channel
- User Interface
- Web, Local GUI
- AI by Camera
- Face detection, Face recognition, Video metadata (Human, Motor vehicles, and Non-motor vehicles), Perimeter protection, IMD, Stereo analysis, Crowd distribution, People counting, ANPR, Heat map, PPE detection
- Video Output
- 2 VGA:1920 × 1080, 1280 × 1024, 1280 × 720; 2 HDMI:3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
- Face Detection AI by NVR
- Sub screen 4K enabled: 4 Channels (up to 12 face images/sec each channel) Sub screen 4K disabled: 8 Channels (up to 12 face images/sec each channel)
- Face Detection AI by Camera
- 32 Channels
- Face Recognition AI by NVR
- Sub screen 4K enabled: 16 Channel FD (by camera) + FR (by recorder), image stream: 32 face images/sec 4 Channel FD (by recorder) + FR (by recorder), Video stream: 16 face images/sec Sub screen 4K disabled: 16 Channel FD (by camera) + FR (by recorder), image stream: 32 face images/sec 8 Channel FD (by recorder) + FR (by recorder), Video stream: 16 face images/sec
- Face Attributes
- 6 attributes
- Face Database Capacity
- Up to 20 face databases with 200,000 images, with a total capacity of 44G
- Decoding Capability
- AI disabled: 2 Channel 32MP@30fps, 2 Channel 24MP@30 fps, 4 Channel 16MP@30 fps, 5 Channel 12MP@30 fps, 8 Channel 8MP@30 fps, 10 Channel 6MP@30 fps, 12 Channel 5MP@30 fps, 16 Channel 4MP@30 fps, 32 Channel 1080p@30 fps, 64 Channel 720p@30 fps AI enabled: 1 Channel 32MP@30 fps, 1 Channel 24MP@30 fps, 2 Channel 16MP@30 fps, 4 Channel 12MP@30 fps, 6 Channel 8MP@30 fps, 8 Channel 6MP@30 fps, 8 Channel 5MP@30 fps, 12 Channel 4MP@30 fps, 24 Channel 1080p@30 fps, 48 Channel 720p@30 fps, 64 Channel D1@30 fps
- License Plate Database Capacity
- 1. Up to 20,000 plate numbers, 2. Blocklist and allowlist
- Non-motor Vehicle
- 4 attributes
- Disk Interface
- 8 SATA ports each disk can contain up to 20TB, this limit varies depending on the environment temperature
- IMD+ by Camera
- Human and vehicle detection on all channels, supporting up to 64 targets per second
- Network Bandwidth
- AI disabled: 512 Mbps incoming, 512 Mbps recording and 512 Mbps outgoing AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
- Resolution
- 32MP, 24MP, 16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 2MP, 960p, 720p, D1, CIF, QCIF
- People Attributes
- 9 human body attributes
- Intelligent Alarm
- Face detection, Face recognition, Video metadata (Human, Motor vehicle, and non-motor vehicle), Perimeter protection, License plate comparison
- RAID
- RAID 0/1/5
- Playback Mode
- Instant playback, General playback, Event playback, Tag playback, Smart playback
- Multi-channel Playback
- Up to 16 channels
- Protocols
- HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, InstaOn, Auto connect, ISCSI, ONVIF (Profile T, Profile S, Profile G), CGI, SDK
- Power Redundancy
- Support
- Video Compression
- Instastream, H.265, H.264+, H.264, MJPEG
- Audio Compression
- G.711a, G.711u, PCM, G726
- Audio Input
- 1 Channel RCA
- Audio Output
- 2 Channel RCA
- Alarm Input
- 16 Channels
- Alarm Output
- 8 Channels (1 channel 12 V 1 A output）
- Backup Mode
- USB device and network
- Interface Ports
- 4 USB (2 front USB 2.0 ports, 2 rear USB 3.0 ports), 2 HDMI, 2 VGA, 2 RS485 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication), 1 RS232, 1 eSATA
- Ethernet Port
- 2 (10/100/1000 Mbps Ethernet port, RJ-45)
- Smart Phone
- iOS, Android
- Browser
- Chrome, IE, Safari, Edge, Firefox
- Power Supply
- 100–240 VAC, 50/60 Hz
- Power Consumption
- <13 W (without HDD)
- Operating Temperature
- –10°C to +55°C (14°F to +131°F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Storage Temperature
- –10°C to +55°C (14°F to +131°F)
- Dimensions
- 444.0 mm × 476.0 mm ×95.0 mm
- Weight
- 8790 g
