Up to 128 Channels IP camera input
Max. 1280/1280/1024 Mbps Incoming/Recording/Outgoing bandwidth
Support 16 SATA HDDs up to 20TB Each, 4 USB Ports
Supports N+M cluster
Support Raid 0/1/5/6/10
Support Intellicheck with up to 64 Channels
- AI by NVR
- 8 Channels face detection and recognition, Up to 40 face databases and 300,000 face images, 8 Channels metadata, 32 Channels perimeter protection, 32 Channels IMD+
- AI by Camera
- Face detection and recognition, Perimeter protection, IMD+, Metadata, ANPR, Stereo analysis, Heat map, and people counting
- Mobile Software
- iCMOB, gCMOB
- CMS Software
- KVMS Pro Lite
- Processor
- Industrial-grade processor
- IP Camera Input
- 128 Channels
- Operating System
- Embedded Linux
- User Interface
- Web, Local GUI
- Video Output
- 2 VGA, 4 HDMI
- 2 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
- 4 HDMI 1&2: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
- HDMI 3: 7680 × 4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
- HDMI 4: 1920 × 1080, 1280 × 1024, 1280 × 720 Simultaneous mode (Simultaneously outputs video sources for all the HDMI 1-4 and VGA 1-2 ports) Max. resolution of VGA 1 and VGA 2 is 1080p
- Max. resolution of HDMI 1 and HDMI 2 is 4K
- Max. resolution of HDMI 3 is 8K
- Max. resolution of HDMI 4 is 1080p Heterogeneous mode (simultaneously outputs video sources for the VGA 1 and HDMI 1, or VGA 2 and HDMI 2. It also outputs heterogeneous video sources for HDMI 1–4) Max. resolution of VGA 1 and VGA 2 is 1080p
- Max. resolution of HDMI 1, HDMI 2 and HDMI 3 is 4K
- Max. resolution of HDMI 4 is 1080p
- Video Compression
- Instastream, H.265, H.264
- AI by Camera
- Face detection, Face recognition, Video metadata (Human, Motor vehicles, and non-motor vehicles), Perimeter protection, IMD, Stereo analysis, Crowd distribution, People counting, ANPR, Heat map, PPE detection
- AI by NVR
- Face detection, Face recognition, Video metadata (Human, Motor vehicles, and non-motor vehicles), Perimeter protection, IMD+
- ANPR by Camera (Number of Channels)
- 64 Channels
- License Plate Database Capacity
- 1. Up to 20,000 plate numbers 2. Blocklist and allowlist
- Perimeter Performance AI by NVR
- Simultaneous mode: 32 Channels, 10 IVS rules for each channel Heterogeneous mode: 24 Channels, 10 IVS rules for each channel Refer to the information on video output for details on the mode
- Perimeter Performance of AI by Camera
- 64 Channels
- IMD+ by Camera
- 128 Channels
- IMD+ by NVR
- 32 Channels: Secondary filtering for human and motor vehicle, Reducing false alarms caused by leaves, Rain and lighting condition change
- Resolution
- 32MP, 24MP, 16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080p, 960p, 720p, D1, CIF
- Audio Input
- 1 Channel RCA
- Audio Output
- 2 Channel RCA
- Audio Compression
- G.711a, G.711u, PCM, G726, AAC
- Face Attributes
- 6 attributes
- Face Detection Performance of AI by NVR
- Simultaneous mode: 8 Channels (up to 12 face images/sec each channel) Heterogeneous mode: 5 Channels (up to 12 face images/sec each channel) Refer to the information on video output for details on the mode
- Face Detection Performance of AI by Camera
- 64 Channels
- Face Recognition Performance of AI by NVR
- Simultaneous mode: 32 Channel FD (by camera) + FR (by recorder), Image stream: 32 face images/sec, 8 Channel FD (by recorder) + FR (by recorder), Video stream: 16 face images/sec Heterogeneous mode: 16 Channel FD (by camera) + FR (by recorder), Image stream: 16 face images/sec, 5 Channel FD (by recorder) + FR (by recorder), Video stream: 10 face images/sec Refer to the information on video output for details on the mode
- Face Database Capacity
- Up to 40 face databases with 300,000 images, with a total capacity of 48G
- Face Recognition Performance of AI by Camera
- 64 Channels
- Metadata Performance of AI by NVR
- 8 Channels, 23 attributes extraction
- Metadata Performance of AI by Camera
- 64 Channels
- Multi-channel Playback
- Up to 16 Channels
- Decoding Capability
- AI disabled: 2 Channel 32MP@30 fps, 2 Channel 24MP@30 fps, 4 Channel 16MP@30 fps, 5 Channel 12MP@30 fps, 8 Channel 8MP@30 fps, 11 Channel 6MP@30 fps, 12 Channel 5MP@30 fps, 16 Channel 4MP@30 fps, 32 Channel 1080p@30 fps, 128 Channel D1@30 fps AI enabled: 1 Channel 32MP@30 fps, 1 Channel 24MP@30 fps, 2 Channel 16MP@30 fps, 2 Channel 12MP@30 fps, 4 Channel 8MP@30 fps, 5 Channel 6MP@30 fps, 6 Channel 5MP@30 fps, 8 Channel 4MP@30 fps, 16 Channel 1080p@30 fps, 80 Channel D1@30 fps
- Multi-screen Display
- Main Screen: 1/4/8/9/16/25/36/64 Sub Screen: 1/4/8/9/16/25/36
- Playback Mode
- Instant playback, General playback, Event playback, Tag playback, Smart playback
- Motor Vehicle Attributes
- 9 Attributes
- Non-motor Vehicle Attributes
- 4 Attributes
- Network Bandwidth
- AI disabled: 1280 Mbps incoming, 1280 Mbps recording and 1024 Mbps outgoing AI enabled: 640 Mbps incoming, 640 Mbps recording and 512 Mbps outgoing
- People Attributes
- 9 human body attributes
- Intelli check AI by Camera + NVR
- Max. 64 Channel, 1 combined event per channel
- Alarm Input
- 32 Channels
- Alarm Output
- 16 Channels
- General Alarm
- Motion detection, Local alarm, Alarm box, Camera external alarm, Network alarm, Scene changing, PIR alarm, Thermal alarm
- Abnormality Alarm
- Error (No disk, Disk error, Low space, RAID exception, Low quota space, Abnormal disk health, Network disconnection, IP conflict, MAC conflict, Abnormal fan speed), Video loss, Video tampering, Camera offline, Audio detection
- Intelligent Alarm
- Face detection, Face and body detection, Face recognition, Perimeter protection, IMD, Video metadata, Stereo analysis, Crowd distribution, ANPR, Heat map
- Alarm Linkage
- Record, Snapshot (panoramic), Local alarm output, IPC external alarm output, Access controller, Audio, Buzzer, Log, Preset, Email
- RAID
- 0/1/5/6/10
- Hot Swapping
- Support
- Interface Ports
- 4 (2 front USB 2.0 ports, 2 rear USB 3.0 ports), 2 RS485 (1 port for half-duplex serial communication, 1 port for full-duplex serial communication), 1 RS232, 1 eSATA
- Disk Group
- Support
- Protocols
- HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, Multicast, InstaOn, Auto connect, Iscsi, ONVIF (Profile T, Profile S, Profile G), CGI, SDK
- Record Mode
- General, Motion detection, Intelligent, Alarm, POS
- Hard Disk
- 16 SATA ports, each disk can contain up to 20 TB. this limit varies depending on the environment temperature
- Backup Method
- USB device and network
- Smart Phone
- iOS, Android
- Ethernet
- 4 (10/100/2500 Mbps Ethernet port, RJ-45)
- Network Mode
- Multi-address, Load balance, Fault tolerance
- Browser
- Chrome, IE, Safari, Edge, Firefox
- Power Supply
- 100–240 VAC, 50±2% Hz
- Redundant Power
- Support
- Power Consumption
- <25 W (without HDD)
- Operating Temperature
- –10°C to +55°C (14 °F to +131 °F)
- Operating Humidity
- 10%–93% (RH), non-condensing
- Dimensions
- 485.0 mm × 529.0 mm × 133.2 mm (W × D × H)
- Weight
- 13030g
