High-performance stream media transfer and storage capability
Support local storage and IP-SAN storage
Support GIS map (Google, Raster Map)
Support ONVIF
Support intelligent device connection
Front panel can displays system service status
Real-time live video monitoring with flexible layouts
AI-powered target search and movement analysis
Zone-based access control with remote door management
Two-way video intercom with emergency communication
Max. Capacity per Storage Server (Local and IPSAN): Single Server: 200 TB; Multiple Servers: 1 PB
- Processor
- Intel i5-12400, 64 bits 6 Core Processor
- Operating System
- Embedded Linux
- Memory
- 16 GB
- System Disk
- Seagate 7200 RPM Enterprise Class HDD 6 TB
- Motherboard
- Embedded board (24x7 Operation)
- Hard disk hot swap
- Support hot swap and online replacement
- Hard disk compatibility
- SAS/SATA disk
- Power Redundancy
- 1+1 redundant power
- Ethernet
- 4 Ethernet ports (100/1000 Mbps)
- Interface Ports
- 2 × USB 2.0 on front panel; 2 × USB 3.0 on rear panel, 4 HDMI ports, 1 VGA port
- HDD Installation
- Support 15 HDDs (3.5
- Storage
- Up to 200 TB per server
- HDD Mode
- Single
- Bandwidth of Video Storage per
- 600 Mbps
- Roles
- 100
- Users (PC Client and EVMS Pro)
- 50 online users and 200 total users
- Roles per User
- 32
- User Groups
- 20
- Users per User Group
- 200
- General Recording Plans
- 3,000
- Event Sources for Event Rules
- 3,000
- Combined Event Rules
- 100
- Combined Events
- 1,000
- Generic Event Rules
- 50
- Hierarchies
- 8
- Max. Size of Raster Map
- 15MB
- Raster Maps
- 256
- Resources on GIS Map
- 300 (After merging); 2,000 (Before merging)
- Resources per Raster Map
- 300 (After merging); 2,000 (Before merging)
- Persons and Vehicle Groups
- 999
- Group Levels
- 10
- Cards
- 200,000
- Faces
- 100,000
- Vehicles
- 20,000
- Vehicle Watch Lists
- 16
- Persons for Door Access Rules
- 10,000 (1 password, 2 face images, 3 fingerprints, and 5 cards for each person)
- Zones
- 256
- Door Access Rules
- 200
- Public Passwords
- 1,500
- Appointments in Progress
- 10,000
- People Counting Groups
- 8
- People Counting Rules Per Group
- 20
- Vehicles.
- 20,000
- Vehicle Groups
- 256
- Main Parking Lots
- 8
- Entrances
- 64
- Entrance/Exit Points
- 64
- Rules of Sending Scheduled Reports
- 32
- Notification Center Message
- 1,000
- Quick Commands per User
- 20
- Event Records
- 5,000,000
- ANPR Records
- 5,000,000
- Metadata Records
- 5,000,000
- Access Records
- 5,000,000
- Video Intercom Records
- 5,000,000
- Historical Count Records
- 5,000,000
- In Area Statistical Records
- 5,000,000
- Heat Map Records
- 5,000,000
- Entrance Records
- 5,000,000
- People Entering and Exit Records
- 5,000,000
- Forced Exit Records
- 5,000,000
- Service Logs
- 5,000,000
- Power
- Max. power 315 W, Stable power 210 W
- Working Temperature
- 0°C to +40°C (+32°F to +104°F)
- Working Humidity
- 10%–80% (RH), non-condensing
- Storage Temperature
- –20°C to +70°C (–4°F to +158°F)
- Storage Humidity
- 5%–90% (RH), non-condensing
- Working Altitude
- 0 m–5000 m (0 ft–16,404.20 ft)
- Dimension
- 444.8 mm × 133.2 mm × 522.2 mm
- Weight
- 19100g
- Sub Servers
- 5 servers
- Devices
- Single Server: 2,000 devices; Multiple Servers: 6,000 devices
- Auto Connect Devices
- Single Server: 1,000 devices; Multiple Servers: 5,000 devices
- Add Devices by ONVIF
- Single Server: 500 devices, 1,000 channels; Multiple Servers: 2,500 devices, 5,000 channels
- Face Recognition Devices and Channels
- Single Server: 20 devices, 100 channels; Multiple Servers: 100 devices, 500 channels
- Devices Accessed via RTSP
- Single Server: 500 devices, 1,000 channels; Multiple Servers: 2,500 devices, 5,000 channels
- Access Control Devices
- Single Server: 200 devices; 500 doors; Multiple Servers: 600 devices; 1,500 doors
- Alarm Controller
- Single Server: 64 devices; 640 zones; Multiple Servers: 320 devices; 3,200 zones
- Emergency Phone Towers
- Single Server: 20 devices; 40 channels; Multiple Servers: 100 devices; 200 channels
- Heat Map Channels
- Single Server: 32 channels; Multiple Servers: 160 channels
- Total Incoming Bandwidth
- Single Server: 600 Mbps; Multiple Servers: 3,000 Mbps
- Incoming Video Bandwidth
- Single Server: 600 Mbps; Multiple Servers: 3,000 Mbps
- Incoming Picture Bandwidth
- Single Server: 100 Mbps; Multiple Servers: 500 Mbps
- Total Outgoing Bandwidth
- Single Server: 600 Mbps; Multiple Servers: 3,000 Mbps
- Outgoing Video Bandwidth
- Single Server: 600 Mbps; Multiple Servers: 3,000 Mbps
- Outgoing Picture Bandwidth
- Single Server: 100 Mbps; Multiple Servers: 500 Mbps
- Total Storage Bandwidth
- Single Server: 600 Mbps; Multiple Servers: 3,000 Mbps
- Video Storage Bandwidth
- Single Server: 600 Mbps; Multiple Servers: 3,000 Mbps
- Prerecording Bandwidth for Alarm Recordings
- Single Server: 400 Mbps; Multiple Servers: 2,000 Mbps
- Storage of Events or Alarms without Pictures
- Single Server: 240 per sec; Multiple Servers: 480 per sec
- Combined Event
- Server: 100 per sec
- Access Control Events
- Single Server: 240 per sec; Multiple Servers: 480 per sec
- CPU
- Recommended: Intel® Core i7-11700 @2.50 GHz; Minimum: Intel® Core i5-9500 @3.00 GHz
- Memory.
- 16 GB
- Graphics Card
- Recommended: NVIDIA® GeForce® RTX 3060; Minimum: Intel® UHD Graphics 630
- Hard Drive Capacity
- Recommended: 200 GB free space for EVMS Pro Client; Minimum: 100 GB free space for EVMS Pro Client
- Ethernet Port
- 1,000 Mbps
- Client Operating System
- Microsoft® Windows 10 20H2 Pro (32-bit) Microsoft® Windows 10 20H2 Pro (64-bit) Microsoft® Windows 11 21H2 Pro (64-bit)
