8, 1000Mbps; RJ45 ports; IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt
Communication standard IEEE802.3/IEEE802.3u/IEEE 802.3ab/IEEE802.3x
Intelligent PoE, PoE watchdog, Long distance PoE
PoE Power 96W
Easy and safe installation
- Communication Standard
- IEEE802.3/IEEE802.3u/IEEE 802.3ab/IEEE802.3x
- PoE Standard
- IEEE802.3af; IEEE802.3at; Hi-PoE; IEEE802.3bt
- Switch Capacity
- 20 Gbps
- Packet Forwarding Rate
- 14.88 Mpps
- MAC Table Size
- 4K
- Statics Protection
- Air discharge: 8 kV Contact discharge: 6 kV
- PoE Pin Assignment
- 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
- Long Distance PoE Transmission
- 250 m long distance PoE transmission
- Data Transmission Port
- Port 1–8: 8 × RJ-4510/100/1000 Mbps (PoE) Port 9-10: 2 × RJ-45 10/100/1000 Mbps (Uplink)
- Packet Buffer Memory
- 1.5 Mbit
- Thunder-proof
- Common mode: 4 kV Differential mode: 2 kV
- Operating Temperature
- –10 °C to +55 °C (+14°F to +131°F)
- Storage Temperature
- –20 °C to +70 °C (–4°F to +158°F)
- Operating Humidity
- 5% – 95% (RH)
- Storage Humidity
- 5% – 95%(RH)
- PoE Power
- 96 W
- Power Consumption
- Idling: 3 W, Full load: 96 W
- Power Supply
- 48 V - 57 V DC
- Dimensions
- 190 mm × 100 mm × 30 mm
- Weight
- 0.50 kg
