5 MP PS CMOS Image Sensor
Max 25 fps@5MP
DWDR, Day/Night (ICR), 2D NR, BLC, HLC
3.6mm fixed lens (2.8mm optional)
Support Built-in Mic
IR Range of 30 Mtrs., Warm Light Range of 20 Mtrs.
4 Signals over 1 Coaxial Cable
- Image Sensor
- 5MP PS CMOS Image Sensor
- Minimum Illumination
- 0.02 lux F2.0 (Color, 30 IRE) 0.002 lux F2.0 (B/W, 30 IRE) 0 lux (IR on)
- Max. Resolution
- 2880 (H) × 1620 (V)
- Shutter Speed
- 1/25 s–1/100,000 s/ NTSC: 1/30 s–1/100,000 s
- White Balance
- Auto, Area white balance
- Lens
- 3.6mm (2.8mm optional)
- Lens Type
- Fixed-focal
- Max. Aperture
- F2.0
- DORI Distance
- 2.8 mm: Detect:66.0 mtr., Observe: 26.4 Mtr., Recognize: 13.2 Mtr., Identify: 13.2 Mtr. 3.6 mm: Detect: 76.0 Mtr., Observe: 30.4 Mtr., Recognize: 15.2 Mtr., Identify : 7.6 Mtr.
- Lens Mount
- M12
- Close Focus Distance
- 2.8 mm:1.0 m ; 3.6 mm: 1.3 m
- Gain Control (AGC)
- Auto
- Pan, Tilt, Rotation
- Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360°
- S/N Ratio
- More than 55dB
- Angle of View
- 2.8 mm: H: 106°; V: 56°; D: 125° 3.6 mm: H: 92°; V: 48°; D: 10°
- Back Light Compensation
- BLC/HLC/DWDR
- Video Streaming
- CVI: PAL: 5M@25 fps, 4M@25 fps, 1080p@25 fps, NTSC: 5M@25 fps, 4M@30 fps, 1080p@30 fps AHD: PAL: 4M@25 fps, NTSC: 4M@30 fps TVI: PAL: 4M@25 fps, NTSC: 4M@30 fps CVBS: PAL: 960H, NTSC: 960H
- Resolution
- 5M (2880 × 1620), 4M (2560 × 1440), 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
- Noise Reduction
- 2D NR
- Privacy Mask
- Off/On (4 areas, rectangle)
- Day/Night
- Auto(ICR)/Color/B/W
- IR Distance
- IR Range of 30 Mtr.
- Warm Light Distance
- Warm Light Range of 20 Mtr.
- IR Mode
- Smart IR&WL, WL Mode
- IR Control
- Fixed
- Operating Temperature
- –40 °C to +55 °C (–40 °F to +131 °F)
- Operating Humidity
- <95% (RH), non-condensing
- Storage Temperature
- –40 °C to +55 °C (–40 °F to +131 °F)
- Storage Humidity
- <95% (RH), non-condensing
- Power Source
- 12 VDC ± 30%
- Power Consumption
- Max 2.6W (12V DC, WLED on)
- Dimension
- 85mm × 771mm
- Weight
- 0.11 kg
