1/2.7” 2.4MP CMOS Image Sensor (0.9407 cm)
Max 25/30fps@2.4MP
DWDR, Day/Night (ICR), 2D-DNR, AWB, AGC, BLC, HLC
3.6mm fixed lens (2.8mm optional)
IR Range of 20 Mtrs. , Smart IR, IP67
Support Built-in Mic
OSD Menu, control over coaxial cable, 2D-DNR
HD, SD and Two Analog format Output switchable
- Image Sensor
- 1/2.7” 2MP CMOS Image Sensor (0.9407 cm)
- Minimum Illumination
- 0.04Lux/F2.0, 30IRE, 0Lux IR on
- Shutter Speed
- PAL: 1/25s–1/100000s ; NTSC: 1/30s–1/100000s
- Lens
- 3.6mm (2.8mm optional)
- S/N Ratio
- More than 65dB
- Lens Type
- Fixed lens/ Fixed Iris
- Mount Type
- Board-in
- Max Aperture
- F2.0
- Angle of View
- 2.8mm; D:120° H:100° V:53° ; 3.6mm: D:99° H:83° V:44
- Close Focus Distance
- 3.6mm– 0.8m ; 2.8mm– 0.6m
- DORI Distance
- 2.8mm: D:46.9m; O:18.8m; R:9.4m; I:4.7m 3.6mm: D:53.7m; O:21.5m; R:10.7m; I:5.4m
- Back Light Compensation
- BLC/HLC/DWDR
- White Balance
- Auto/ Manual
- Video Streaming
- 2.4MP@25/30fps, 25/30/50/60fps@720P
- Video Output
- 1-channel BNC high definition video output/ CVBS video output (Can switch)
- ICR
- Auto (ICR)/Manual
- Audio
- Built-in Mic
- IR
- IR Range of 20 Mtr., Smart IR
- IR Control
- Auto/ Manual
- OSD Menu
- Multi-language
- Casing
- Plastic
- Operating Temperature
- -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH
- Storage Temperature
- -40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH
- Weatherproof Standard
- IP67
- Power Source
- 12V DC ±30%
- Power Consumption
- Max 2.7W (12V DC, IR on)
- Dimension
- 70mm x 70mm x 149mm (2.76
- Weight
- 0.14Kg.
