2.4MP PS CMOS Image Sensor
Max. 2.4MP (1920 x 1080)@25/30fps
DWDR, Day/Night (ICR), 2D DNR, AWB, AGC, BLC
3.6mm Fixed lens (2.8mm and 6mm optional)
IR Range of 30 Mtrs., IP67
OSD Menu, control over coaxial cable, 2D-DNR
CVI/CVBS/AHD/TVI switchable
- Image Sensor
- 2.4MP PS CMOS Image Sensor
- Max. Resolution
- 1920 (H) × 1080 (V)
- Minimum Illumination
- 0.02 lux@F2.0 (Color, 30 IRE), 0.002 lux@F2.0 (B/W, 30 IRE), 0 lux (IR on
- Shutter Speed
- PAL: 1/25 s–1/100,000 s, NTSC: 1/30 s–1/100,000 s
- Lens
- 3.6mm (2.8mm and 6mm optional)
- Angle Adjustment
- Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°
- Lens Type
- Fixed-focal
- Lens Mount
- M12
- Max. Aperture
- F2.0
- Angle of View
- 3.6 mm: H: 80°, V: 43°, D: 94°; 2.8 mm: H: 100°, V: 54°, D: 117°; 6 mm: H: 43°, V: 24°,
- Close Focus Distance
- 3.6 mm: 0.8 m; 2.8 mm: 0.5 m; 6 mm: 2.4 m
- DORI Distance
- 3.6mm– 55.0m (Detect), 22.0m (Observe), 11.0m (Recognize), 5.5m (Identify) 2.8mm– 44.7m (Detect), 17.9m (Observe), 8.9m (Recognize), 4.5m (Identify) 6mm– 102.9m (Detect), 41.1m (Observe), 20.6m (Recognize), 10.3 (Identify)
- Back Light Compensation
- BLC/DWDR
- Iris Control
- Fixed
- White Balance
- Auto
- Video Output
- Video output choices of CVI/TVI/AHD/CVBS by one BNC port
- Noise Reduction
- 2D DN
- Gain Control (AGC)
- Auto
- Day/Night
- Auto(ICR)/Color/B/W
- Resolution
- 1080p (1920 × 1080), 960H (960 × 576/960 × 480)
- Frame Rate
- CVI: PAL: 1080p@25 fps NTSC: 1080p@30 fps AHD: PAL: 1080p@25 fps NTSC: 1080p@30 fps TVI: PAL: 1080p@25 fps NTSC: 1080p@30 fps CVBS: PAL: 960H NTSC: 960H
- IR Mode
- Smart IR
- IR
- IR Range of 30 Mtr.,
- IR Control
- Auto
- Operating Temperature
- -40°C ~ +60°C (-40°F ~ +140°F)
- Operating Humidity
- <95% (RH), non-condensing
- Storage Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity
- <95% (RH), non-condensing
- Power Source
- 12V DC ±30%
- Power Consumption
- Max. 2.8 W (12 VDC, IR on)
- Dimension
- 146.1 mm × 70.0 mm × 69.8 mm
- Weight
- 0.15 Kg.
