1/2.7” 5MP PS CMOS Image Sensor (0.9407 centimetres)
DWDR, Day/Night (ICR), 2D DNR,BLC, HLC
3.6mm fixed lens (2.8 mm, 6mm optional)
IR Range of 30 Mtrs., Warm Light Range of 20 Mtrs., IP67
4 Signals over 1 Coaxial Cable
Support Built-in Mic
- Image Sensor
- 1/2.7” 5MP PS CMOS Image Sensor (0.9407 centimetres)
- Minimum Illumination
- 0.02 lux@F2.0 (Color, 30 IRE), 0.002 lux@F2.0 (B/W, 30 IRE), 0 lux (IR on)
- Max. Resolution
- 2880 (H) × 1620 (V)
- Shutter Speed
- PAL: 1/25~1/100000s NTSC: 1/30~1/100000s
- White Balance
- Auto, Area white balance
- Gain Control (AGC)
- Auto
- DORI Distance
- 3.6 mm: Detect: 76.0 Mtr., Observe-30.4 Mtr., Recognize: 15.2 Mtr., Identify: 7.6 Mtr. 2.8 mm: Detect: 66.0 Mtr., Observe: 26.4 Mtr., Recognize: 13.2 Mtr., Identify: 6.6 Mtr. 6 mm: Detect: 120.0 Mtr. , Observe: 48.0 Mtr. , Recognize: 24.0 Mtr., Identify : 12.0 Mtr.
- Lens Type
- Fixed-focal
- Max. Aperture
- F2.0
- Lens Mount
- M12
- Close Focus Distance
- 3.6mm: 1.3Mtr., 2.8mm: 1.0Mtr., 6mm: 2.8Mtr.
- Lens
- 3.6mm, 6mm(2.8mm optional)
- Back Light Compensation
- BLC/HLC/DWDR
- Angle Adjustment
- Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360°
- Angle of view
- 2.8 mm: H: 106°, V: 56°, D: 125° 3.6 mm: H: 92°, V: 48°, D: 109° 6 mm: H: 54°, V: 29°, D: 62°
- S/N Ratio
- >65 dB
- Resolution
- 5M (2880 × 1620), 4M (2560 × 1440), 2MP (1920 × 1080), 960H (960 × 576/960 × 480)
- Video Output
- Video output choices of CVI/TVI/AHD/CVBS by one BNC port
- Video Streaming
- CVI: PAL: 5M@25 fps, 4M@25 fps, 2M@25 fps, NTSC: 5M@25 fps, 4M@30 fps, 2M@30 fps AHD: PAL: 4M@25 fps, NTSC: 4M@30 fps, TVI: PAL: 4M@25 fps, NTSC: 4M@30 fps, CVBS: PAL: 960H, NTSC: 960H
- Noise Reduction
- 2D NR
- Privacy Mask
- Off/On (8 areas, rectangle)
- Day/Night
- Auto(ICR)/Color/B/W
- Mirror Function
- Support
- IR
- IR Range of 30 Mtr.,
- IR Control
- Auto, Manual
- Warm Light Range
- Warm Light Range of 20 Mtr.
- IR Mode
- Smart IR&WL, WL Mode, IR Mode
- Dual LED Number
- 2 (Warm light) + 2 (IR light)
- Iris Control
- Fixed
- Anti-corrosion Level
- Basic Protection
- Audio
- Built-in Mic
- Weatherproof Standard
- IP67
- Operating Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Operating Humidity
- <95% (RH), non-condensing
- Storage Temperature
- –40 °C to +60 °C (–40 °F to +140 °F)
- Storage Humidity
- <95% (RH), non-condensing
- Power Source
- 12VDC ±30%
- Power Consumption
- Max 4.0 W (12V DC, WLED on)
- Casing
- Plastic
- Dimension
- 146.1mm × 70.0mm × 69.8mm
- Weight
- 0.17kg.
