1/2.7” 5MP PS CMOS Image Sensor (0.9407 cm)
DWDR, Day/Night (ICR), 2D DNR, BLC, HLC
3.6mm Fixed lens (2.8mm Optional)
IR Range of 30 Mtrs., Smart IR
Support Built-in Mic
- Image Sensor
- 1/2.7” 5MP PS CMOS Image Sensor (0.9407 cm)
- Minimum Illumination
- 0.02 Lux/F2.0, 30 IRE, 0 Lux IR on
- Max. Resolution
- 2880 (H) × 1620 (V)
- Shutter Speed
- PAL: 1/25 s–1/100000 s, NTSC: 1/30 s–1/100000 s
- Angle Adjustment
- Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360°
- White Balance
- Auto, manual
- Lens Mount
- M12
- Gain Control (AGC)
- Auto
- Max. Aperture
- F2.0
- Lens
- 3.6mm Fixed Lens (2.8mm Optional)
- Close Focus Distance
- 3.6 mm: 1.2 m, 2.8 mm: 0.8 m
- DORI Distance
- Lens 3.6mm: 80.0m (Detect), 32.0m (Observe), 16.0m (Recognize), 8.0m (Identify) Lens 2.8mm: 56.0m (Detect), 22.4m (Observe), 11.2m (Recognize), 5.6m (Identify)
- Lens Type
- Fixed
- Angle of View
- 3.6 mm: 104° × 88° × 46°, 2.8 mm: 125° × 106° × 56°
- Back Light Compensation
- BLC, HLC, DWDR
- Resolution
- 5M (2880×1620), 4M (2560×1440), 2M (1920×1080), 960H (960 × 576/960 × 480)
- Video Output
- Video output choices of CVI/TVI/AHD/CVBS by one BNC port
- Frame Rate
- CVI: PAL: 5M@25 fps, 4M@25 fps, 2M@25 fps , NTSC: 5M@25 fps, 4M@30 fps, 2M@30 fps AHD: PAL: 4M@25 fps, NTSC: 4M@30 fps, TVI: PAL: 4M@25 fps, NTSC: 4M@30 fps, CVBS: 960H
- Noise Reduction
- 2D DNR
- Iris Control
- Fixed
- Audio
- Built-in Mic
- Privacy Mask
- Off/On (8 areas, rectangle)
- Audio Interface
- Audio Interface
- Day/Night
- Auto (ICR)/ Manua
- Mirror Function
- Support
- IR Control
- Auto, Manual
- IR
- IR Range of 30 Mtr.,
- Smart IR
- Support
- Operating Humidity
- <95% (RH), non-condensing
- Operating Temperature
- –40°C to +55°C (–40°F to +131°F)
- Power Source
- 12 VDC ± 30%
- Power Consumption
- Max. 2.7W (12 VDC, IR on)
- Dimension
- 85.4mm × 68.8mm
- Casing
- Plastic
- Weight
- 0.09 kg
